CLG842 32E0066 装卸叉（φ850） Handling Fork

1 11D0041 ZL40B.11.2 销 Pin 1
2 00B0055 GB5783-86 螺栓 Bolt M20×40-8.8-Zn.D 3
3 06B0019 GB93-87 垫圈 Washer 20 3
4 06B0016 GB97.1-85 垫圈 Washer 20-140HV-Zn.D 3
5 11D0043 ZL40B.11.9 铲斗下销轴 Lower pin
shaft of bucket
2
6 25D0029 装卸叉体 Handling fork 1
7 11D0052 ZL40B.23.1.2 油缸销（一） Oil cylinder
pin (1)
M12×30-8.8-Zn.D 2
8 00B0017 GB5783-86 螺栓 Bolt M12×30-8.8-Zn.D 6
9 06B0008 GB93-87 垫圈 Washer 12 6
10 06B0007 GB97.1-85 垫圈 Washer 12-140HV-Zn.D 6
11 25D0014 ZL40B.23.1.3 夹紧叉 Clamp fork 10-140HV-Zn.D 2
12 55A0205 ZL40B.23.1-1 轴套 Bearing bush 2
13 35C0013 ZL50C.11.10 密封圈 Seal ring 63×75×8 4
14 11D0053 ZL40B.23.1.4 销子 Pin 2
15 11D0054 ZL40B.23.1.5 油缸销（二） Oil cylinder
pin (2)
2
16 00B0075 GB5783-86 螺栓 Bolt M8×20-8.8-Zn.D 4
17 06B0006 GB93-87 垫圈 Washer 8 4
18 10B0014 GB1152-89 油杯 Oil cup M10×1 9
