CLG835 44C0047 001 方向机安装总成 STEERING CONTROL GROUP

1 35C0087 LGFXP 方向盘 STEERING
WHEEL 1
2 00A0255 ZL20.9.1-5 触头 CONTACT
FINGER 1
3 56A0106 卡环 RETAINING
RING 1
4 76A0040 挡圈 RETAINING
RING 2
5 56A0105 垫圈 WASHER 1
6 21B0012 GB/T276-1994 向心球轴承
1000905 BALL BEARING 25×42×9 1
7 44C0023 转向轴 DIVERT AXES 1
8 10D0329 套管 PIPE 1
9 84A0099 罩板 PLATE 1
10 21B0020 GB/T 276-1994 向心球轴承
1000806 BALL BEARING 30×42×7 1
11 02D0167 支承座 BEARER 1
12 04B0022 GB70-85 螺钉 SCREW M10×25-8.8- ZN.D 4
13 06B0002 GB93-87 垫圈 WASHER 10 8
14 06B0001 GB97.1-85 垫圈 WASHER 10-140HV-ZN.D 4
15 24C0038 可调气弹簧总成 STRUT AS 1
16 84A0100 罩板 PLATE 1
17 02D0168 支座 BEARER 1
18 02D0169 安装支座 BEARER 1
19 00B0017 GB5783-86 螺栓 BOLT M12×30-8.8-ZN.D 8
20 06B0008 GB93-87 垫圈 WASHER 12 8
21 00A0227 ZL30.9.1-1 接头 CONNECTOR 4
22 12B0291 GB1235-76 O形圈 “O” RING 22×2.4 4
23 12B0356 GB3452.1-92 O形圈 “O” RING 10.6×1.8 4
24 44C0048 BZZ1-800 转向器 DIVERTER 1
25 00B0012 GB5783-86 螺栓 BOLT M10×25-8.8-ZN.D 4
26 83A0060 橡胶圈 RUBBER RING 1
27 04B0290 GB818-85 螺钉 SCREW M6×12-4.8-ZN.D
（黑色） 2
28 08B0068 GB882-86 销轴 PIN 10X50 1
29 08B0004 GB91-86 销 COTTER PIN 3.2×20-ZN.D 1
30 66A0015 销 COTTER PIN 2
31 00B0022 GB5783-86 螺栓 BOLT M6×16-8.8-ZN.D 2
32 13A0218 板 PLATE 2
33 61A0132 销 COTTER PIN 2
34 55A0305 轴套 BEARING
BUSH 2
35 22A0146 板 PLATE 3
36 04B0170 GB70-85 螺钉 SCREW M6X10-8.8-ZN.D 6
37 80A0046 ZL40B.9.1-2 绝缘环 INSULATED
RING 1
38 61A0061 ZL40B.9.1-3 铜环 COPPER
COLLAR 1
39 04B0198 GB818-85 螺钉 SCREW M4×12-4.8-ZN.D 1
