Description

13C0020 Check valve for LIUGONG PART

04A0834 flange; Q235
00B0075 Bolt; GB5783-86; M8×20-8.8-Zn.D; STL
16C0041 Cover plate; ASSEM
60A1279 shaft; 35
53A0754 cover; 35
36D0457 cover; WELD
12B0246 O-ring; GB3452.1-92; 200×5.3; YI9424
00B0085 Bolt; GB5783-86; M8×25-8.8-Zn.D; STL
53C0289 Return oil filter; assembly parts
10D2920 Steel pipe assembly; WELD
12B0447 O-ring; SAE J515:2010; 56.74×3.53; NBR-90
01B0016 Bolt; GB5783-86; M8×40-8.8-Zn.D; STL
04D1859 box body; WELD
10A1502 side board; Q235
00B0007 Bolt; GB5783-86; M8×16-8.8-Zn.D; STL
06B0006 Washer; GB93-87; 8; 65Mn
06B0087 Washer; GB96-85; 16-140HV-Zn.D; STL
00C0937 Pilot control line; ASSY
32C0122 Tee connector; ASSY
44C0182 Pilot valve installation assembly; fittings
06B0117 Washer; 14; AGGL
30C0231 connector; ASSY
12C0372 Pilot valve; 5THF6 E XX-20/ST 41 CACC 2Y6 M01 + 2
30C0242 connector; assembly parts
06B0003 Washer; GB93-87; 6; 65Mn
05A0106 Plug; cold drawn hexagonal steel; 35#
04B0256 screw; GB/T 818-2000; M6×16-4.8-Zn.D (black); STL
09C0069 pipe clamp; fittings
21A0942 Upper pipe clamp; Q235
21A0943 Lower pipe clamp; Q235
83A0122 Rubber ring; YI6364
06B0008 Washer; GB93-87; 12; 65Mn
00B0035 Bolt; GB5783-86; M12×35-8.8-Zn.D; STL
05C2533 Hose assembly; ASSY
22C0314 Pilot handle lock; ASSY
05C0604 Hose assembly; fittings
44C0239 Pilot cut-off switch; assembly parts
03B0036 Nut; GB6170-86; M6-8-Zn.D; STL
11A0683 mounting plate; Q235
06B0117 Washer; 14; AGGL
06B0024 Washer; GB97.1-85; 6-140HV-Zn.D; STL
06B0003 Washer; GB93-87; 6; 65Mn
03B0180 Nut; GB6173-86; M14×1.5-05-Zn.D; STL
12C0174 ball valve; ASSY
00B0010 Bolt; GB5783-86; M6×20-8.8-Zn.D; STL
83A0136 Guard ring; Industrial offset A
21A1329 mounting plate; Q235
16D0454 Joystick; welded parts
00A1108 connector; cold drawn hexagonal steel 19/35
06C4211TS hose assembly; ASSY
05C0603TS hose assembly
44C0141 Pressure measuring connector; assembly parts
32C0141 Tee connector; ASSY
06C1429TS hose assembly; fittings
12C1412X1 Pressure reducing valve assembly; ASSEM
00B0064 Bolt; GB5783-86; M10×55-8.8-Zn.D; STL
06B0001 Washer; GB97.1-85; 10-140HV-Zn.D; STL
06B0002 Washer; GB93-87; 10; 65Mn
12C1412 Pressure reducing valve; ASSEM
00A2550 connector; 35
78A0013 valve body
65A0020 Spool; 20CrMnTi
75A0172 Pressure regulating spring
57A0037 Pressure regulating gasket; 45
57A0036 Pressure regulating gasket
12B0353 O-ring; GB3452.1-92; 19×2.65; YI9424
00A1129 connector; 35
06C3522 Hose assembly; ASSEM
05C0601TS hose assembly
00C0896 Steering line; ASSY
07C4959 Hose assembly; ASSY
30C0262 connector; assembly parts
05C5852 Hose assembly; ASSY
09C1562 pipe clamp; ASSY
03B0021 Nut; GB6170-86; M8-8-Zn.D; STL
03B0003 Nut; GB6170-86; M12-8-Zn.D; STL
06A4772 Bent plate; Q235
09C0056 Pipe clamp; ASSY
21A0180 Lower pipe clamp; Q235
21A0181 Upper pipe clamp; Q235
83A0070 Rubber ring; Rubber I-1
06B0008 Washer; GB93-87; 12; 65Mn
00B0013 Bolt; GB5783-86; M12×40-8.8-Zn.D; STL
06B0006 Washer; GB93-87; 8; 65Mn
06B0005 Washer; GB97.1-85; 8-140HV-Zn.D; STL
66C2030 Hose assembly; ASSY
06C3526 Hose assembly; ASSEM
31C0102 Elbow joint; ASSY
44C0173 Steering gear BZZ-125; assembly parts
06B0002 Washer; GB93-87; 10; 65Mn
00B0012 Bolt; GB5783-86; M10×25-8.8-Zn.D; STL
01B0160 Bolt; GB5782-86; M12×100-8.8-Zn.D; STL
12B0569 O-ring; 47.22×3.53; YI8435
00B0064 Bolt; GB5783-86; M10×55-8.8-Zn.D; STL
12C2419 Flow amplification valve installation assembly; ASSY
31C2152 connector; ASSY
30C2576 connector; ASSY
30C0241 Plug; ASSY
30W0073 Tee connector; ASSY
30C0262 connector; assembly parts
