CLG842 11E0041 液压油箱 Hydraulic Oil Tank

1 16C0003 QL-10 空气滤清器 Air filter 1
2 00B0007 GB5783-86 螺栓 Bolt M8X16-8.8-Zn.D 4
3 06B0006 GB93-87 垫圈 Washer 8 4
4 44C0017 YWZ-150T 液位液温计 Level gauge 1
5 74A0057 ZL40B.10.7B-4 提示牌 Bulletin board 1
6 15D0091 回油法兰接头 Flange joint for
oil return
1
7 12B0090 GB3452.1-92 O形圈 O-ring 10.6X1.8 1
8 12B0232 GB3452.1-92 O形圈 O-ring 15X1.8 1
68
9 53C0010 YLX-51-H-12μ 回油滤油器 Oil return filter 1
10 04D0036 箱体 Tank body 1
11 00B0015 GB5783-86 螺栓 Bolt M10X25-8.8-Zn.D 32
12 06B0002 GB93-87 垫圈 Washer 10 32
13 15D0092 吸油法兰接头 Suction flange
joint
1
14 12B0247 GB3452.1-92 O形圈 O-ring 150X5.3 1
15 03B0024 BF25-24 螺栓 Bolt 1
16 12B0008 GB1235-76 O形圈 O-ring 40X3.1 1
17 53C0021 YLX-54-J 吸油滤油器 Suction filter 1
18 75A0057 ZL40B.10.7-2 弹簧 Spring 2
19 02D0160 法兰支座 Flange Support 2
20 12B0111 GB3452.1-92 O形圈 O-ring 21.2X1.8 1
21 00B0093 GB5783-86 螺栓 Bolt M16X30-8.8-Zn.D 6
22 06B0015 GB93-87 垫圈 Washer 16 6
23 06B0047 GB97.1-85 垫圈 Washer 16 6
