XG951 变矩器系统

1 00B1118 GB5783—86 M10x30 24 Bolt
2 06B0003 GB93—87 10 31 Washer
3 52C0001 D135—6 1 Torque
4 06B0072 JB982— 77 30 4 Washer
5 00A0039 403063B M30x1.5 4 Connector
6 07C0023 ZL40. 50— 2 1 Hose
7 07C0583 1 Hose
8* 07C0564 1 Hose
9 00A0035 ZL40. 50—6 M22x1.5 1 Connector
10 06B0073 JB982—77 22 1 Washer
11 12C0066 402320 1 Cover assem
12 10B0070 GB3452. 1 -92 42.5×2. 65 1 O ring
13 65B0015 YL—98 1 Filler element
14 10B0069 GB3452. 1—92 95×3.55 O ring
15 09D0002 402310 1 Housing
16 04B0868 GB70— 85 M8x25 2 Bolt
17 06B0009 GB93—87 8 5 Washer
18 23A2177 1 Bracket
19 00B0068 GB5783—86 M10x38 2 Bolt
20 55A0034 402012A 2 Washer
21 01B0025 GB5782—86 M10x70 5 Washer
22 05B0013 GB897—88 M8x35 1 Blot
23 24A0010 402011 4 Plate
24 30B0005 GB6170—86 M8 2 Nut
25 00B0013 GB5783—86 M8x35 1 Blot
26 07C0176 1 Hose
27 07C0106 1 Hose
