C62.12.21.0000 Manual Air Starting Subsystem Assembly

1 C62.12.07.0002 减压阀接头 Reducing valve joint 1 1 1 1
2 C62.12.07.2000 油雾器 Oil mist bottle 1 1 1 1
3 90037110002 内接头 Sleeve joint G1/4 1 1 1 1 GB/T3289.26
4 C62.12.07.3000 继气器 Air relay 1 1 1 1
5 C62.12.02.2000 焊接管接头
结合子组
Welded pipe joint
subassembly 2 2 2 2
6 C62.12.21.1000 气开关 Air switch 1 1 1 1
7 C62.12.07.1000 气起动马达 Air starter 1 1 1 1
8 C62.12.07.0006 垫片 Washer 1 1 1 1
9 C62.12.07.0005 法兰弯头 Flange bend 1 1 1 1
10 90033040029 内六角头螺钉 Inner hex. head bolt 4 4 4 4 GB/T70.1-M12×25
11 90033040028 内六角头螺钉 Inner hex. head bolt 4 4 4 4 GB/T70.1-M12×20
12 C62.12.07.5000 消声器 Muffler 1 1 1 1
13 C62.12.07.0003 垫片 Washer 1 1 1 1
14 JKY-Z6A 卡套式接头
M10×1
Sleeve joint 6 6 6 6
