D02C-000-95 飞轮壳组件 FLYWHEEL HOUSING GROUP

1 B00002111 六角法兰面螺栓 HEX HEAD BOLT (FLANGED) 4 Q/SC622-M6*12

2 D02C-149-03 飞轮壳开口盖板 FLYWHEEL HOUSING INSPECTION OPENING COVER 1

3 B00001728 六角头螺塞 HEXAGON PIPE PLUG 1 Q/SC587.1-M18*1.5

4 B00002110 六角法兰面螺栓 HEX HEAD BOLT (FLANGED) 2 Q/SC622-M6*10

5 D02C-104-07 盖板 COVER 1

6 B00002132 六角法兰面螺栓 HEX HEAD BOLT (FLANGED) 2 Q/SC622-M8*16

7 D02C-107-01 夹箍 CLAMP 1

8 D02C-103-01 指针 INDICATOR 1

9 B00002147 六角法兰面螺栓 HEX HEAD BOLT (FLANGED) 1 Q/SC622-M8*45

10 B00000846 六角法兰面螺母 NUT, HEX FLANGE HEAD CAP 1 GB/T6177-M8-Y

11 D02A-163-02 内六角螺塞 PLUG 1

12 D02C-105-01 盖板垫片 GASKET 1

13 D02C-104-06 盖板 COVER 1

14 D02C-109-02 垫片 GASKET 1

15 D02C-102-07 启动电机连接法兰 STARTING MOTOR FLANGE 1

16 D02C-106-01 盘车孔塞 BARRING BORE PLUG 1

17 B00000300 O形橡胶密封圈 O-RING 1 GB/T3452.1-23.6*3.55

18 B00001284 平垫圈 PLAIN WASHER 3 GB/T97.1-16-200HV-Y

19 D02C-110-01 十二角头螺栓 12-POINT HEAD BOLT WITH FLANGE 3

20 D02C-108-02 启动电机垫片 STARTING MOTOR GASKET 1

21 D02C-101-48 飞轮壳 FLYWHEEL HOUSING 1

22 U562A-M5M6213 六角锥管螺塞 PLUG 1
