前传动轴中间轴及支承 Front Drive Shaft Medium Shaft And Support

1 W-04-00009 1 孔用弹性挡圈 Snap ring 4 00005-
2 1 防尘圈 Ring 4 00005-
3 W-04-00013 1 十字轴轴承总成 Neddle bearing ass’y 4 00005-
4 W-04-00010 1 平衡片 Balancing piece 1 00005-
5 Z30.3B-2 1 突缘叉 Flange yoke 1 00005-
6 W-04-00012 1 十字轴20MnVB Universal joint cross 1 00005-
7 B-J07940B-00001 1 油杯45° M10×1 Grease fitting 2 00005-
8 Z30.5B.1.1 1 前传动轴叉 Front drive shaft yoke 1 00005-
9 B-G000910-00051 1 销5×50ZnD Pin 1 00005-
10 W-04-00027 1 支架轴承油封总成 Oil seal ass’y 2 00005-
11 W-04-00011 1 轴承前盖 Front cover 1 00005-
12 B-G002760-00019 1 滚动轴承6210 Bearing 1 00005-
13 W-04-00004 1 垫环 Back-up ring 1 00005-
14 W-04-00006 1 轴承后盖 Rear cover 1 00005-
15 Z30.5.2-2 1 螺栓M10×1×82 Bolt 3 00005-
16 Z30.5A.1-2 1 突缘 Flanged sleeve 1 00005-
17 Z30.5A.1-1 1 垫圈 Washer 1 00005-
18 B-G061710-00002 1 螺母M10×1 Nut 3 00005-
19 B-Q020440-00003 1 螺母M27×1.5 ZnD Nut 1 00005-
20 B-G000930-00001 1 垫圈10 Washer 3 00005-
21 B-G008890-00005 1 螺母M14X1.5ZnD Nut 8 00005-
22 B-G00097B-00006 1 垫圈14ZnD Washer 12 00005-
23 B-G057860-00019 1 螺栓M14X1.5X45ZnD Bolt 8 00005-
