滤清器总成  Filter Ass’y

1 Z30.4.21-12 1 铝垫 Al-pad 2 00005-
2 Z30.4.21.1 1 滤清器罩 Filter boot 1 00005-
3 Z30.4.21-3 1 滤清器罩下端盖 Cover 1 00005-
4 Z30.4.21-11 1 滤网 Screen 1 00005-
5 Z30.4.21-10 1 滤清器骨架 Skeleton 1 00005-
6 Z30.4.21-6 1 垫 Pad 1 00005-
7 Z30.4.21-7 1 盖板 Cover 1 00005-
8 B-Q020710-00104 1 O形圈 90×3.1 O-ring 1 00005-
9 Z30.4.21-8 1 法兰盘 Flange 1 00005-
10 B-Q020710-00070 1 O形圈 45×3.5 O-ring 1 00005-
11 Z30.4.21-2 1 联接螺杆 Screw 1 00005-
12 Z30.4.21-4 1 油管 Tube 1 00005-
13 Z30.4.21-9 1 接头 Joint 1 00005-
14 B-Q020710-00042 1 O形圈 25×2.4 O-ring 1 00005-
15 B-G000910-00023 1 销 2×36 ZnD Cotter pin 1 00005-
16 B-G061780-00002 1 螺母 M10 ZnD Nut 1 00005-
17 Z30.14.8.3-3 1 隔垫 Spacer 15 00005-
18 Z30.14.8.3-2 1 永磁铁 Magnet 4 00005-
19 Z30.4.21-1 1 铝管 Al-pipe 1 00005-
20 Z30.4.21-5 1 滤清器上端盖 Cover 1 00005-
21 B-J010020-00001 1 垫圈 10 Washer 4 00005-
22 B-G057830-00012 1 螺栓 M10×35 ZnD Bolt 4 00005-
23 B-G000930-00017 1 垫圈 8 Washer 4 00005-
24 B-G057830-00143 1 螺栓 M8×25 ZnD Bolt 4 00005-
