Description

YJ315L-00005 Driving gear in driving oil pump  for LONKING CDM833 spare parts

GB276-82 球轴承116 Ball bearing 116 1
403101 旋转油封 Rotary seal 1 LG853.03.01.01-001
403103 输入二级齿轮 Second stage input gear 1 LG853.03.01.01-003
403102 旋转油封 Rotary seal 1 LG853.03.01.01-002
GB301 推力球轴承5111（55X78X16） Thrust ball bearing 5111 1
403104 输入一级齿轮 First stage input gear 1 LG853.03.01.01-004
GB276 球轴承6311 （55X120X29） Ball bearing 6311 1
403105 调整垫片 Adjusting shims 1 LG853.03.01.01-005

GB6171-86 螺栓M10×1 Bolt M10×1 20
GB859-87 垫圈 10 Washer 10 20
403201 螺栓 Bolt 20
403202 调整圈 Spacer 1 LG853.03.01.02-001
GB276 球轴承6110 Ball bearing 6110 1
403203 中间输入轴 Intermediate input shaft 1
GB276-82 球轴承110 Ball bearing 110 2
GB893-76 挡圈 80 Spacer 80 1
403204-209B 超越离合器 Overrunning clutch 1 LG853.03.01.02.01
403210 隔离套 Sleeve 1
GB276-82 球轴承 210 Ball bearing 210 2
403221 隔离圈 Sleeve 1
403222 调整圈 Spacer 1
403213A 倒档行星架 Reverse planet carrier 1 LG853.03.01.02-003
403215 止动垫圈 Stop washer 4 LG853.03.01.02-004
GB/T93 垫圈 8 Washer 8 4
GB/T5780 螺栓 M18×40 Bolt M18×40 4
403216 倒档内齿圈 Reverse internal ring gear 1 LG853.03.01.02-005
403217 行星轮垫片 Planet gear washer 16 LG853.03.01.02-006
403218 行星轮 Planet gear 8 LG853.03.01.02-007
GB309-76 滚针4×35 Needle 4×35 176
403219 隔离套 Separating sleeve 16 LG853.03.01.02-008
403220 卡圈 Snap ring 1 LG853.03.01.02-009
403221 倒档行星轮轴 Reverse planet gear shaft 4 LG853.03.01.02-010
403222A 一档内齿圈 Speed I internal ring gear 1 LG853.03.01.02-011
403223 一档行星架 Speed I planet carrier 1 LG853.03.01.02-012
