Description

W370001900B Front lamp (left)

1 远近光开关 Switch W370001220B
1
2 前组合灯(左) Front lamp (left) W370001900B
1
3 变速杆密封套 Seal sleeve Z3A00422300
4
4 螺栓 M12×140 Bolt M12×140 B040810047
4
5 螺母 M12 Nut M12 B050331211
4
6 垫圈 12 Washer 12 B060411203
4
7 前组合灯支架组件 Front combine lamp Bracket MG19550001
1
8 前组合灯（右） Front combine lamp（R） W370001910B
1

1
温度传感器 Temperature Sensor W370000410B ES120-0030 2
发动机水温接头 Engine temperature adapter Z6B55000400 1
2
后车架线束组件 Rear Frame Wiring Harness MG19022001 1
3
扎带 Clip W110001370 ZD200×8 57
4
油量传感器 Oil Level Sensor W46000029 104288003 1
5
直流接触器 Direct Contact Device W110009610 MZJ100A/006 2
6
前后工作灯 Front And Rear Work Light W370000940B 9
前后工作灯灯泡
Front And Rear Work Light
Bulb W370001580B 9
7
后组合灯(带倒车灯) Rear Combined Lamp W370000790B 2
刹车灯灯泡 Brake Bulb W370001920B 2
倒车灯灯泡 Reversing Lamp Bulb W110007020 2
转向灯泡 Steering Bulb W110010190 2
行车灯灯泡 Travel Lamp Bulb W370000791B 2
8
倒车报警器 Backup Alarm W370000250B Wide long 1
9
倒车报警器支架 Backup Alarm Bracket MG19022018 1
10
变速箱油压压力开关 Switch W46000017 1
11
霍尔转速传感器 Hall Speed Sensor W46000030 115000201 2

12 发动机搭铁线
Engine Ground Line Z5B55001400 1
13
低气压压力开关 Low Air Pressure Switch W370000380B
PS31-40-2MNB-B-T
S-FS4BARF 2
14
脚制动气压压力开关
Foot Brake Air Pressure
Switch W370000430B
PS31-30-2MNB-A-T
S-FS2.45BARF 2
15
机油压力开关 Oil Pressure Switch W46000018
PS31-20-2MNB-B-I
P-FS0.6BARF 1
16
起动机电瓶线 Starter Battery Cables MG19022013 1
17
护套（启动马达处红色）
Jacket（Start Motor, Red
Color） W370000070 1
18
后工作灯支座 Rear Work Lamp Bracket MG19022015 2
护套 Jacket Z320050080 2
21
前组合灯(左) 组合件 Front Combined Lamp (Left) W370001900B 2
远近光灯泡 The Distance Light Bulb W370002000B 2
转向灯炮 Turn Light Bulb W110010190 2
行车灯灯泡 Travel Lamp Bulb W370002100B 2
22
前组合灯（右） 组合件 Front Combined Lamp（Right） W370001910B 2
远近光灯泡 The Distance Light Bulb W370002000B 2
转向灯炮 Turn Light Bulb W110010190 2
行车灯灯泡 Travel Lamp Bulb W370002100B 2
