Description

SP103410 seat shock absorber

42C0278 减速机 GM8B1000-00 REDUCTIONG GEAR ASSY
70A0434 轮毂 266B1001-00 HUB
78A0323 定子 263B1002-05 SPINDLE
34C1447 主轴总成 277B1132-00 SPINDLE ASSY
04A1154 法兰盖 246B1003-00 HOLD FLANGE
41A0262 齿轮 283B1004-01 RV GEAR A
41A0263 齿轮 283B1005-01 RV GEAR B
41A0266 主动齿轮 293B1006-00 INPUT GEAR
41A0267 从动齿轮 293B1007-00 SPUR GEAR
53A0994 端盖 293B1008-00 COVER
40A0104 曲柄轴 200B1009-012 CRANK SHAFT
55A2851 定距片 200B1014-01 DISTANCE PIECE
41C0531 联轴器 269B1015-00 COUPRING
20B0180 滚针 225B1017-00 PIN
277B1019-001 REAMER BOLT
56A1213 卡环 150A1020-00 SNAP RING
21B0135 球轴承 200B1021-01 BALL BEARING
23B0150 圆锥滚子轴承 650D1022-00 TAPERED ROLLER BEARING
20B0181 滚针轴承 283B1023-00 NEEDLE ROLLER BEARING
07B0372 挡圈 JB2804S35 SNAP RING FOR SHAFT
12B1344 O形圈 JB2401P7-90 O-RING
12B1345 O形圈 ARP568-378-70 O-RING
12B1346 O形圈 JW1516G37-70 O-RING
13B0769 浮动密封 ES100-250BA627 FLOATING SEAL
03B1145 螺塞 GM1/2 HEX SOCKET PLUG
04B0630 内六角螺钉 JB1176M12*30-12L HEX SOCKET HEAD BOLT
20B0182 钢球 JB1501-3/8 STEEL BALL
11C0787 马达 281B2000-019-MF CONTROL VALVE ASSY
04A1153 法兰盖 281B2091-00 REAR FLANGE
63A0242 轴 269B2002-00 SHAFT
52A0554 斜盘 263B2003-01-M SWASH PLATE
50A0349 缸体 263B2004-04 CYLINDER BLOCK
50A0356 柱塞 263B2005-01 PISTON
15C0253 柱塞组件 263B2040-01 PISTON ASSY
55A2872 滑靴 277B2006-00 SHOE
10A4289 卡板 277B2007-00 RETAINER PLATE
20B0183 止推球 263B2008-01 THRUST BALL
52A0553 配油盘 276B2009-00 TIMING PLATE
56A1217 垫圈 880A2010-00 WASHER
56A1218 垫圈 263B2011-03 WASHER
50A0351 活塞 266B2012-00 PISTON
75A0552 弹簧 800A2013-00 SPRING
75A0553 弹簧 277B2014-00 SPRING
10A4291 摩擦片 800A2015-001 FRICTIONG PLATE
10A4292 摩擦板 800A2016-00 MATING PLATE
10A4293 摩擦板 263B2074-00 MATING PLATE
05A0261 螺塞 610B2021-00 PLUG
65A0374 阀杆 266B2050-00-F SPOOL
05A0260 螺塞 860A2051-00 PLUG
76A0169 弹簧座 869A2052-00 SPRING RETAINER
05A0659 螺塞 860A2053-02 PLUG
12C1845 阀 860A2054-01 VALVE
75A0231 弹簧 860A2056-00 SPRING
75A0554 弹簧 860A2055-01 SPRING
13B0768 油封 15Z25*42*10 OIL SEAL
12B1348 O形圈 266B2035-00 O-RING
12B1349 O形圈 JB2401P26-90 O-RING
12B1350 O形圈 JB2401P16-90 O-RING
12B1351 O形圈 JB2401P18-90 O-RING
12B1352 O形圈 266B2039-00 O-RING
12B1353 O形圈 JB2401P11-90 O-RING
08B0327 定位销 JB1354-4*10 PARALLEL PIN
08B0328 定位销 JB1354-10*25 PARALLEL PIN
04B0631 内六角螺钉 JB1176M10*30-12 HEX SOCKET HEAD BOLT
56A1225 卡环 THR42 THS SNAP RING
04B0632 内六角螺钉 GM1/8S HEX SOCKET PLUG
20B0184 滚针轴承 263B2048-00 NEEDLE ROLLER BEARING
21B0136 球轴承 263B2049-00 DEEP GROOVE BALL BEARING
20B0185 滚针 263B2098-00 NEEDLE ROLLER
04B0633 内六角螺钉 GDL1/16S HEX SOCKET HEAD BOLT
50A0357 柱塞 263B2071-001 PISTON
15C0254 柱塞组件 263B2070-01 PISTON ASSY
55A2873 滑靴 263B2072-00 SHOE
12C1846 阀 200B2073-00-B VALVE
50A0354 制动活塞 300B2039-00 STOPPER
56A1227 环 300B2042-00 RING
75A0555 弹簧 300B2043-01 SPRING
60A1626 枢轴 263B2076-02 PIVOT
20B0182 钢球 JB1501-3/8 STEEL BALL
55A2874 轴套 263B2014-00 COLLER
04B0634 内六角螺钉 JB1176M8*65-12 HEX SOCKET HEAD BOLT
66A0085 销 263B2077-01 PARALLEL PIN
56A1228 止动垫圈 SWM8 SUPER LOCK WASHER
53C0386 过滤器 976B2079-00 FILTER
12C1850 节流阀 121F2070-00 ORIFICE
75A0556 弹簧 263B2090-001 SPRING
05A0415 堵头 512B2021-00 PLUG
10A2694 铭牌 850A0006-D0 NAME PLATE
12C1847 阀 247B3002-00 VALVE
12C1848 控制阀 247B3000-01-0C SRV2 C
55A2875 阀套 246B3003-00 SLEEVE
75A0557 回位弹簧 247B3004-00 SPRING RETAINER
05A0660 螺塞 247B3005-00 PLUG
57A1039 薄垫片 247B3006-00 SHIM
75A0558 弹簧 247B3008-00 SPRING
JB2041P14-90 O-RING
JB2041P20-90 O-RING
JB2041P16-90 O-RING
07B0373 挡圈 JB2407T2P14 BUCK UP-RING
70A0435 阀体 249B3001-01 BODY
50A0355 活塞 247B3007-00 PISTON
05A0261 螺塞 610B2021-00 PLUG
05A0415 堵头 512B2021-00 PLUG
20B0182 钢球 JB1501-3/8 STEEL BALL
07B0374 挡圈 JB2407T3P20 BACK UP-RING
04B0633 内六角螺钉 GDL1/16S HEX SOCKET HEAD BOLT
12C1851 节流阀 S0508 ORIFICE
12B1353 O形圈 JB2401P11-90 O-RING
12B1351 O形圈 JB2401P18-90 O-RING
88A0859 密封包
42C0159 减速机组件 730B1000-00 REDUCTION GEAR ASSY
70A0241 轮毂 719B1001-00 HUB
34C0871 主轴组件 671B1102-05 SPINDLE KIT
34C0872 主轴组件 671B1132-05 SPINDLE ASSY
671B1002-05 SPINDLE
671B1003-03 HOLD FLANGE
671B1019-00 HEX,SOCK BOLT
671B1034-01 PARALLEL PIN
671B1037-00 WASHER
34C0873 RV齿轮组件 671B1104-03 RV GEAR ASSY
671B1204-01 RV GEAR KIT
671B1004-01 RV GEAR A
671B1005-01 RV GEAR B
671B1009-01 CRANK SHAFT
671B1012-03 SPACER
671B1022-00 TAPER ROLLER BEARING
671B1023-01 NEEDLE ROLLER BEARING
40A0058 输入齿轮 681B1006-00 INPUT GEAR
34C0874 正齿轮组件 681B1107-01 SPUR GEAR KIT
681B1007-01 SPUR GEAR
53A0666 端盖 671B1008-03 COVER
56A0561 定距块 671B1013-02 DISTANCE PIECE
34C0879 联轴器 50F1024-00 COUPLING
60A1126 销子 671B1017-00 PIN
07B0268 卡环 JIS B 2804-**95 SNAP RING
SA0355 ANGULAR BALL BEARING
07B0269 卡环 JIS B 2804-**40 SNAP RING
12B0922 O形圈 JIS B 2401-P8-90 O-RING
12B0917 O形圈 JIS B 2401-G230-70 O-RING
12B0999 O形圈 JIS B 2401-P335-70 O-RING
34C0884 浮动密封包 KS207-336*368*40.8-B FLOATING SEAL KIT
207-27-61331 FLOATING SEAL
05A0261 螺塞 610B2021-00 HEX,SOCK PLUG
02B0193 内六角螺栓 JIS B 1176-M12*30-12.9L HEX,SOCK BOLT
20B0097 钢球 JIS B 1501-7/16 STEEL BALL
66A0133 定位销 671B2077-01 PARALLEL PIN
12B0921 O形圈 JIS B 2401-P18-90 O-RING
12C1165 控制阀组件 698B4000-00-B CONTROL VALVE ASSY
34C0889 后法兰组件 698B4100-00-B REAR FLANGE ASSY
34C0890 后法兰组件 698B4101-00-B REAR FLANGE KIT
698B4001-00 REAR FLANGE
671B4050-01-B SPOOL
682B4081-00-A PISTON
05A0412 堵头 100A2051-00 PLUG
56A0562 止动块 140F2052-00-A STOPPER
05A0413 堵头 120F2053-00 PLUG
12C1166 阀 120F2054-00 VALVE
75A0305 弹簧 100A2055-00 SPRING
120F2055-00 SPRING
12B1000 O形圈 JIS B 2401-P32-90 O-RING
12B1001 O形圈 JIS B 2401-P22A-90 O-RING
05A0414 堵头 GM-1/4-K-S HEX,SOCK PLUG
05A0415 堵头 512B2021-00 PLUG
05A0257 内六角螺塞 GDL-1/16-S HEX,SOCK PLUG
12B0921 O形圈 JIS B 2401-P18-90 O-RING
05A0261 螺塞 610B2021-00 PLUG
12B1002 O形圈 JIS B 2401-P11-90 O-RING
12B0919 O形圈 JIS B 2401-P14-90 O-RING
65A0218 阀芯 678B4069-00 SPOOL
75A0307 弹簧 678B4089-00 SPRING
20B0098 钢球 JIS B 1501-3/8 STEEL BALL
53C0199 过滤器 263B2079-01 FILTER
05A0255 螺塞 810B2021-00 PLUG
05A0416 堵头 682B4082-00 PLUG
JIS B 2041-P5-90 O-RING
JIS B 2041-P8-90 O-RING
20B0099 钢球 JIS B 1501-7 STEEL BALL
53C0199 过滤器 263B2079-01 FILTER
05A0256 内六角螺塞 GM-1/8-S HEX.SOCK PLUG
10A2694 铭牌 850A0006-D0 NAME PLATE
66A0134 定位销 JIS B 1354-6*14 PARALLEL PIN
JIS B 1176-M12*40-12.9 HEX.SOCK BOLT
11C0535 马达组件 671B2000-00-C MOTOR SUB ASSY
15C0172 缸体组件 671B2205-00 CYLINDER&PISTON KIT
671B2040-03 PISTON ASSY
671B2005-02 PISTON
671B2006-01 SHOE
671B2004-01 CYLINDER BLOCK
671B2007-00 RETAINER PLATE
671B2008-00 THRUST BALL
80W0015-01 WASHER
671B2011-01 COLLAR
671B2014-02 SPRING
JIS B 2804-**62 SNAP RING
JIS B 1506-3.5*27.8F ROLLER
15C0173 柱塞组件 401B2070-00-A PISTON ASSY
401B2071-01-A PISTON
401B2072-01 SHOE
62A0084 马达轴 671B2002-00 SHAFT
52A0363 斜盘 671B2003-01-C SWASH PLATE
52A0364 配流盘 671B2009-01 TIMING PLATE
50A0224 柱塞 671B4012-02 PISTON
75A0308 弹簧 671B4013-00 SPRING
57A0294 摩擦片 671B4015-00 FRICTION PLATE
57A0295 啮合片 120F2016-00 MATING PLATE
80A0358 油封 TCN-38*58*11 OIL SEAL
12B0535 O形圈 671B4035-00 O-RING
671B4039-01 O-RING
41C0157 轴承 671B2048-00 BALL BEARING
21B0089 球轴承 671B2049-00 BALL BEARING
61A0705 枢轴 671B2076-02 PIVOT
66A0133 定位销 671B2077-01 PARALLEL PIN
75A0309 弹簧 401B2093-00 SPRING
12C1167 溢流阀 671B3000-03 RELIEF VALVE
671B3100-03-OA VALVE KIT
671B3002-02 VALVE
671B3003-03 SLEEVE
671B3004-01 SPRING RETAINER
671B3005-00 PLUG
247B3006-00 SHIM
671B3008-01 SPRING
JIS B 2401-P16-90 O-RING
JIS B 2401-P22-90 O-RING
12B0921 O形圈 JIS B 2401-P18-90 O-RING
JIS B 2407-T2-P16 BAKE-UP RING
JIS B 2407-T2-P22 BAKE-UP RING
JIS B 2401-P29-90 0-RING
SPGO7.5-10.5-1.5 PISTON SEAL
80A0359 修理包
500D1000-011 REDUCTION GEAR ASSY
70A0151 轮毂 500D1001-00 HUB
34C0759 定子套件 500D1102-00 SPINDLE KIT
34C0760 定子组件 500D1132-00 SPINDLE ASSY
500D1002-00 SPINDLE
500D1003-00 HOLD FLANGE
01B0466 螺栓 500D1019-00 REAMER BOLT
500D1104-001 RV GEAR ASSY
34C0763 RV齿轮套件 500D1204-00 RV GEAR KIT
500D1004-00 RV GEAR A
500D1005-00 RV GEAR B
410D1009-00 CRANK SHAFT
910D1012-00 SPACER
500D1022-00 SPACER
410D1023-00 NEEDLE ROLLER BEARING
41A0138 齿轮 500D1006-00 INPUT GEAR
34C0764 行星轮套件 500D1107-00 SPUR GEAR KIT
500D1007-00 SPUR GEAR
53A0513 端盖 500D1008-00 COVER
40A0045 轴 500D1015-00 SHAFT
20B0060 滚针 500D1017-00 PIN
07B0202 挡圈 810B1018-00 RING
07B0203 卡环 860A1013-00 SNAP RING
21B0060 球轴承 500D1021-003 ANGULAR BALL BEARING
07B0204 挡圈 JISB2804-19 SNAP RING
07B0205 挡圈 JISB2804-25 SNAP RING
12B0759 O形圈 JISB2401-P8-90 O-RING
12B0760 O形圈 JISB2401-G230-70 O-RING
12B0761 O形圈 JISW1516-G35-70 O-RING
34C0765 浮动密封包 ES100-204*232*32B FLOATING SEAL KIT
12B0758 浮动密封 ES100-204-B FLOATING SEAL
05A0254 螺塞 410D1033-01 HEX SOCK PLUG
05A0255 螺塞 810B2021-00 HEX SOCK PLUG
12B0429 O形圈 JISB2401-P14-90 O-RING
20B0061 钢球 JISB1501-3/8 STEEL BALL
08B0180 销 JISB1354-8*22 PARALLEL PIN
506D4000-009-P CONTROL VALVE ASSY
506D4100-009-P REAR FLANGE ASSY
506D4101-009-P REAR FLANGE KIT
502D4091-00 REAR FLANGE
266B2050-00-H SPOOL
05A0260 螺塞 860A2051-00 PLUG
76A0169 弹簧座 869A2052-00 SPRING RETAINER
65A0123 阀 500D4054-00 VALVE
75A0231 弹簧 860A2056-00 SPRING
75A0232 弹簧 500D4055-00 SPRING
12B0764 O形圈 JISB2401-P26-90 O-RING
12B0430 O形圈 JISB2401-P18-90 O-RING
JIS B 2401-P18-90 O-RING
05A0256 内六角螺塞 GM-1/8-S HEX SOCK PLUG
20B0064 钢球 JISB1501-3/16 STEEL BALL
502D4069-00 SPOOL
AOS-4 OIL-STOPPER
05A0257 内六角螺塞 GDL-1/16-S HEX SOCK PLUG
53C0199 过滤器 263B2079-01 FILTER
39A0268 节流孔 S0505 ORIFICE
75A0233 弹簧 500D4089-00 SPRING
05A0261 螺塞 610B2021-00 PLUG
05A0258 螺塞 571B2079-001 PLUG
05A0262 螺塞 200C2021-00 PLUG
12B0759 O形圈 JISB2401-P8-90 O-RING
50A0162 活塞 500D3007-00 PISTON
850A0006-DO NAME PLATE
66A0086 定位销 JISB1354-4*10 PARALLEL PIN
00B0423 内六角螺栓 JISB1176-M12*30-12.9 HEX SOCK BOLT
500D2000-00-A MOTOR SUB ASSY
34C0766 柱塞套件 500D2105-00 PISTON KIT
500D2140-03 PISTON ASSY
500D2005-00 PISTON
500D2006-00 SHOE
78A0131 转子 500D2004-00 CYLINDER BLOCK
07B0206 止动片 500D2007-00 RETAINER PLATE
20B0062 球 500D2008-00 THRUST BALL
06B0304 垫圈 500D2010-00 WASHER
75A0228 弹簧 500D2014-00 SPRING
07B0207 挡圈 IRTW-36 THS SNAP RING
20B0063 滚针 500D2098-00 NEEDLE ROLLER
15C0157 活塞组件 500D2070-00 PISTON ASSY
500D2071-001 PISTON
500D2072-00 SHOE
40A0046 轴 500D2002-00 SHAFT
53A0514 斜盘 500D2003-00-A SWASH PLATE
52A0279 配流盘 500D2009-00 TINING PLATE
50A0161 活塞 500D2012-00 PISTON
75A0227 弹簧 500D2013-00 SPRING
52A0280 摩擦盘 500D2015-00 FRICTION PLATE
52A0281 盘 500D2016-00 MATING PLATE
13B0453 油封 15Z-22*42*10 OIL SEAL
12B0762 O形圈 500D2035-00 O-RING
12B0763 O形圈 500D2039-00 O-RING
21B0061 球轴承 880A2029-00 BALL BEARING
21B0062 球轴承 JISB1521-6301 BALL BEARING
71A0248 枢轴 500D2076-00 PIVOT
66A0085 销 263B2077-01 PARALLEL PIN
75A0229 弹簧 844B2085-001 SPRING
65A0124 阀芯 500D3002-00 VALVE
55A1355 阀套 500D3003-00 SLEEVE
05A0263 螺塞 500D3009-00 PLUG
75A0234 弹簧 500D3008-00 SPRING
12B0765 O形圈 JISB2401-P12-90 O-RING
JIS B 2401-P14-90 O-RING
12B0766 轴封 271B3009-00 O-RING
76A0170 挡圈 JISB2407-T2-P12 O-RING
76A0171 挡圈 JISB2407-T2-P14 O-RING
20B0065 钢球 JISB1501-5/16 STEEL BALL
39A0269 节流孔 S0304 ORIFICE
SO304 ORIFICE
88A0621 修理包 502D9000-00
