P5100-F100NM457 97/P124-G10Y03G gear pump for LONKING CDM856 CDM855E spare parts
1 M1MAKH-16 FLANGE COMPONENTS 法兰组件 2
2
F7811519121212-
1250(PG-119) HOSE 软管 2
3 M1M1KH-12 FLANGE COMPONENTS 法兰组件 14
4 CDM6210.06 BUCKET ROD ASSEMBLY 斗杆总成 1
5 H10229500 BUCKET CYLINDER 铲斗油缸 1
6 GB/T70.1 SCREW M20×35 螺钉 M20×35 8
7 CDM6210.71 BUCKET ASSEMBLY 铲斗总成 1
8 H10229401(RH) RIGHT BOOM CYLINDER 右动臂油缸 1
H10229301(LH) LEFT BOOM CYLINDER 左动臂油缸 1
9 GB/T5783 BOLT M20×30 螺栓 M20×30 2
10 GB/T97.1 WASHER 20 垫圈 20 2
11 CDM6210.05-08 SPRAG D22×5.5 挡圈 D22×5.5 2
12 CDM6210.05.10 BOOM CYLINDER PIN ASSEMBLY 动臂油缸销轴总成 2
13 CDM6210.05-09 PIN WASHER Φ82×12 销轴垫圈Φ82×12 2
14 CDM6210.05.06 HIGH PRESSURE HOSE Φ27 高压油管Φ27 1
15 CDM6210.05.05 HIGH PRESSURE HOSE Φ27 高压油管Φ27 1
16 CDM6210.05.03 HIGH PRESSURE HOSE Φ34 高压油管Φ34 1
17 CDM6210.05.02 HIGH PRESSURE HOSE Φ27 高压油管Φ27 1
18 F7811515121212-1100 HOSE 软管 1
19 F7811519161616-1170 HOSE 软管 1
20 124 O-RING Ф24.99×3.55 O 形圈Ф24.99×3.55 3
21 H10229200 BUCKET CYLINDER 斗杆油缸 1
22 CDM6210.05 BOOM ASSEMBLY 动臂总成 1
23 CDM6210.05.08 HIGH PRESSURE HOSE Φ27 高压油管Φ27 1
24 CDM6210.05.07 HIGH PRESSURE HOSE Φ27 高压油管Φ27 1
1 CDM6210.71.01 BUCKET 铲斗本体 1
2 GB/T5782 BOLT M16×150 螺栓 M16×150 2
3 GB/T6170 NUT M16 螺母 M16 4
4 CDM6210.71.02 PIN ASSEMBLY 销轴总成 2
5 LG6230.15-09 ADJUST SHIMS 调整垫片 4
6 GB/T3452.1 O RING Φ145×10 O 形圈Φ145×10 4
7 GB/T6170 NUT M24 螺母 M24 10
8 GB/T1230 WASHER 24 垫圈 24 10
9 S/C-6230L LEFT CORNER TOOTH 左侧齿板 1
10 GB/T5782 BOLT M24×70 螺栓 M24×70 10
11 S/C-6230R RIGHT CORNER TOOTH 右侧齿板 1
12 GB/T5782 BOLT M16×150 螺栓 M16×150 1
13 SPRING-6230 SNAP RING 扣环 5
14 PIN-6230 PIN 销 5
15 P-6230 TOOTH SLEEVE 齿套 5
1 CDM6210.75.01 BUCKET 铲斗本体 1
2 GB/T5782 BOLT M16×150 螺栓 M16×150 2
3 GB/T6170 NUT M16 螺母 M16 4
4 CDM6210.71.02 PIN ASSEMBLY 销轴总成 2
5 LG6230.15-09 ADJUST SHIMS 调整垫片 4
6 GB/T3452.1 O RING Φ145×10 O 形圈Φ145×10 4
7 GB/T6170 NUT M20 螺母 M20 12
8 GB/T1230 WASHER 22 垫圈 22 12
9 EX200-L LEFT CORNER TOOTH 左侧齿板 1
10 GB/T5782 BOLT M20×70 螺栓 M20×70 12
11 EX200-R RIGHT CORNER TOOTH 右侧齿板 1
12 GB/T5782 BOLT M16×150 螺栓 M16×150 1
13 SPRING-6230 SNAP RING 扣环 4
14 PIN-6230 PIN 销 4
15 P-6230 TOOTH SLEEVE 齿套 4
