Description

72A0006 Right bucket tooth body for LIUGONG spare part

46C5292 battery circuit
08C2949 Battery positive cable
37B0004 Nylon cable tie
37B0108 battery
05B0072 Double-end stud
06B0396 Washer
03B0289 Nut
08C2952 cable
06B0395 Washer
00B0256 Bolt
21A1746 Negative switch mounting plate
34B0087 negative switch
08C2951 Battery negative cable
08C2950 connecting cable
46C3890 lamp assembly
46C2406 headlight assembly
45D0380 guard
06B0066 Washer
06B0017 Washer
04B0066 screw
32B0405 work light 32B0140
06B0395 Washer
00B0257 Bolt
21A8589 Bent plate
10A7200 board
32B0066 wall lamp
46C2367 Rear lamp assembly
32B0405 work light 32B0140
03B0661 Nut
06B0395 Washer
00B0257 Bolt
21A3784 Bent plate
21A3787 bracket
46C5560 front-end line
38B0011 Electric Horn
08C4409 Headlight wiring harness
37B0009 cable tie
06B0395 Washer
00B0257 Bolt
46C5563 Frame line
00B0426 Bolt
06B0396 Washer
20A1854 wire clamp
37B0004 Nylon cable tie
22C0568 switch bracket
06B0022 Washer
04B0341 screw
34B0582 Limit switch
08C4421 Frame wiring harness
34B0581 button
46C3439 Relay Box
05B0072 Double-end stud
03B0289 Nut
00B0524 Bolt
03B0661 Nut
06B0395 Washer
00B0540 Bolt
46C5559 console line
83A0131 Guard ring
08C4413 instrument panel wiring harness
00B0381 Bolt
06B0397 Washer
34B0683 Combination switch
46C2952 Instrument Components
35B0099 Voltmeter
35B0141 meter
35B0097 Torque converter oil temperature gauge
35B0096 Engine Water Temperature Gauge
35B0038 timer
00B0569 Bolt
06B0395 Washer
04D0691 Instrument rack assembly
34B0118 Electric lock
46C2922 Instrument cover assembly
06B0396 Washer
00B0426 Bolt
02B0097 Double-ended stud
03B0289 Nut
20A1854 wire clamp
37B0009 cable tie
03B0661 Nut
06B0024 Washer
04B0057 screw
74A0388 Timer Three Packs Warning Sign
46C5556 engine wiring
30B0423 oil pressure sensor
08C4414 Engine wiring harness
37B0009 cable tie
06B0396 Washer
00B0426 Bolt
20A1854 wire clamp
30B0392 temperature sensor
30B0391 temperature sensor
46C3427 Cab wiring
37B0516 Front transmission assembly
37B0514 Front Scraper
37B0517 Rear drive assembly
37B0515 rear scraper
08C2946 Cab wiring harness
46C0152 car fan (optional when not equipped with air conditioner)
83A0136 Guard ring
84A1003 sheath
34B0498 Combination switch
04B0182 screw
37B0009 cable tie
00B0426 Bolt
06B0396 Washer
32B0140 work light
