Description

34C0085 door lock for liugong spare part

32C0037 12B0271 O-ring; GB3452.1-92; 25.8×3.55; YI9424
32C0037 06B0002 Washer; GB93-87; 10; 65Mn
32C0037 00B0019 Bolt; GB5783-86; M10×30-8.8-Zn.D; STL
10E0179X1 72A0027 pressure plate; ZG270-500
10E0179X1 10C0360 steering cylinder; assembly parts
09C0496 56A0148 Pad; Rubber I-1
09C0496 06B0006 Washer; GB93-87; 8; 65Mn
09C0496 03B0021 Nut; GB6170-86; M8-8-Zn.D; STL
09C0496 00B0085 Bolt; GB5783-86; M8×25-8.8-Zn.D; STL
09C0496 21A4116 Pipe clamp; Q235
09C0496 21A4115 pipe clamp; Q235
09C0061 21A0177 Fixing clip
09C0061 06B0006 Washer; GB93-87; 8; 65Mn
09C0061 00B0007 Bolt; GB5783-86; M8×16-8.8-Zn.D; STL
10E0179X1 00B0012 bolt; GB5783-86; M10×25-8.8-Zn.D; STL
10E0179X1 06C0284 Oil cylinder inlet hose φ13
10E0179X1 06C0283 Oil cylinder inlet hose φ16
10E0179X1 06C0282 Oil return hose φ13
10E0179X1 06C0281 radiator oil inlet hose φ16
10E0179X1 06C0280 radiator oil outlet hose φ16
10E0179X1 06C0279 Steering gear oil inlet hose φ16
10E0179X1 06C0278 Steering gear oil return hose φ16
44C0033X1 44C0033X0 steering gear assembly
44C0033X1 12B0356 O-ring; GB3452.1-92; 16×1.8; YI9424
44C0033X1 06B0002 Washer; GB93-87; 10; 65Mn
44C0033X1 00B0012 Bolt; GB5783-86; M10×25-8.8-Zn.D; STL
10E0179X1 06B0003 Washer; GB93-87; 6; 65Mn
10E0179X1 10C0360 steering cylinder; assembly parts
10E0179X1 00A0114 connector
14E0018 12B0251 O-ring; GB3452.1-92; 30×3.55; YI9424
14E0018 01B0175 Bolt; GB5782-86; M12×150-8.8-Zn.D; STL
14E0018 00B0007 bolt; GB5783-86; M8×16-8.8-Zn.D; STL
14E0018 00B0075 Bolt; GB5783-86; M8×20-8.8-Zn.D; STL
14E0018 15B0064 pipe clamp; Q235
14E0018 06B0006 Washer; GB93-87; 8; 65Mn
11D0016X0 11D0016 Pin shaft assembly; welded parts
10C0203X1 56A0050 Cushion cover; Q235
10C0203X1 35C0013 Sealing ring; 63×75×8; welding parts
10C0203X1 10C0203X0 boom cylinder
10C0203X1 00B0183 bolt; GB5783-86; M18×45-8.8-Zn.D; STL
14E0018 04B0174 screw; GB70-85; M8×30-8.8-Zn.D; STL
14E0018 12B0114 O-ring; GB3452.1-92; 26.5×3.55; YI9424
14E0018 10D2143 Steel pipe assembly
14E0018 10D2144 Steel pipe assembly
14E0018 10D2142 steel pipe assembly
21C0038 06B0060 Washer; GB96-85; 14-140HV-Zn.D; STL
21C0038 21C0038X0 Fuel tank
21C0038 06B0013 Washer; GB93-87; 14; 65Mn
21C0038 00B0038 Bolt; GB5783-86; M14×30-8.8-Zn.D; STL
14E0018 72A0027 pressure plate; ZG270-500
44C0035 83A0052 Pad; Rubber I-1
44C0035 22A0241 Support frame
44C0035 20A1917 pipe clamp
44C0035 06B0008 Washer; GB93-87; 12; 65Mn
44C0035 06B0002 Washer; GB93-87; 10; 65Mn
44C0035 00B0017 bolt; GB5783-86; M12×30-8.8-Zn.D; STL
44C0035 00B0005 Bolt; GB5783-86; M10×20-8.8-Zn.D; STL
14E0018 44C0034 Joystick system; assembly parts
44C0034 38C0243 cover plate; ASSY
44C0034 73A0008 Connecting fork; Q235
44C0034 61A0060X9 One word shaft
44C0034 44C0006 Push-pull flexible shaft; assembly parts
44C0034 35C0001 Knob; glued parts
44C0034 23A0109 Bearing; Q235
44C0034 16D0007 Joystick; welded parts
44C0034 10B0018 Oil cup; GB1153-89; 90°M10×1; ASSY
44C0034 08B0080 pin; GB91-86; 4×20-Zn.D; Q235
44C0034 08B0022 round shoulder pin; 45
44C0034 06B0024 Washer; GB97.1-85; 6-140HV-Zn.D; STL
44C0034 06B0007 Washer; GB97.1-85; 12-140HV-Zn.D; STL
44C0034 06B0006 Washer; GB93-87; 8; 65Mn
44C0034 06B0002 Washer; GB93-87; 10; 65Mn
44C0034 03B0035 Nut; GB6171-86; M10×1-8-Zn.D; STL
44C0034 00D0374 bracket
44C0034 00B0012 Bolt; GB5783-86; M10×25-8.8-Zn.D; STL
44C0034 00B0010 Bolt; GB5783-86; M6×20-8.8-Zn.D; STL
44C0034 00B0007 bolt; GB5783-86; M8×16-8.8-Zn.D; STL
44C0032 22A0344 Fixing seat
44C0032 20A0154 pointer; Q235
44C0032 16A0591 Indicator rod
44C0032 06B0006 Washer; GB93-87; 8; 65Mn
44C0032 00B0075 Bolt; GB5783-86; M8×20-8.8-Zn.D; STL
44C0032 00B0026 Bolt; GB5783-86; M8×12-8.8-Zn.D; STL
14E0018 35C0013 Seal ring; 63×75×8; welded parts
33C0007 22A0240 support
33C0007 06B0002 Washer; GB93-87; 10; 65Mn
33C0007 03A0096 Tee connector; Q235
33C0007 00B0005 bolt; GB5783-86; M10×20-8.8-Zn.D; STL
14E0018 31C0020 oil return joint
31C0020 15D0040 connector
31C0020 12B0302 O-ring; GB3452.1-92; 46.2×3.55; YI9424
31C0020 06B0002 Washer; GB93-87; 10; 65Mn
31C0020 00B0012 Bolt; GB5783-86; M10×25-8.8-Zn.D; STL
14E0018 30A0129 Suction hose
14E0018 27A0046 pipe clamp; Q235
14E0018 15B0017 Double steel wire hoop; 60; ASSY
14E0018 12C0087 Multi-way valve; assembly parts
14E0018 10D0411 Steel pipe assembly
14E0018 10D0410 Steel pipe assembly
14E0018 10C0057X0 bucket cylinder
