Description

34B0141 Boom travel switch for liugong spare part

00E0511X1 01B0127 Bolt; GB5782-86; M20×120-8.8-Zn.D; STL
00E0511X1 15B0017 Double steel wire hoop; 60; ASSY
00E0511X1 06B0117 Washer; 14; AGGL
00E0511X1 06B0019 Washer; GB93-87; 20; 65Mn
00E0511X1 06B0006 Washer; GB93-87; 8; 65Mn
00E0511X1 04B0002 screw; 45
00E0511X1 17B0028 Elastic block; glued part
00E0511X1 64A0060 Tie rod
00E0511X1 55A0300 sets; Q235
00E0511X1 54C0006 Drinking line L1800
23C0024 50C0028 accelerator pedal; fittings
23C0024 23C0001X0 ball joint; assembly parts
23C0001 08B0002 pin; GB91-86; 1.6×12-Zn.D; Q235
23C0001 83A0001 Rubber ball head lining; rubber I-1
23C0001 73A0004 Ball joint seat; ZG270-500
23C0001 53A0003 gland; 35
23C0001 06B0003 Washer; GB93-87; 6; 65Mn
23C0001 04B0001 ball head screw; 35
23C0001 03B0036 Nut; GB6170-86; M6-8-Zn.D; STL
23C0024 06B0003 Washer; GB93-87; 6; 65Mn
23C0024 03B0036 Nut; GB6170-86; M6-8-Zn.D; STL
23C0024 00B0022 Bolt; GB5783-86; M6×16-8.8-Zn.D; STL
21C0024X1 21C0024 diesel tank
21C0024X1 06B0013 Washer; GB93-87; 14; 65Mn
21C0024X1 06B0009 Washer; GB97.1-85; 14-140HV-Zn.D; STL
21C0024X1 00B0232 bolt; GB5783-86; M14×50-8.8-Zn.D; STL
00E0511X1 00B0026 Bolt; GB5783-86; M8×12-8.8-Zn.D; STL
01E0016X2 03B0201 Rim nut; 35
01E0016X2 03B0195 Lock nut CB083033-3; M30×2
01E0016X2 01E0016X0 Front axle assembly; 30E
01E0016X0 24D0005X1 axle housing wheel side; 30E
24D0005X1 61A0097 Wheel side reduction support shaft; 40Cr
01E0016X0 74A4621 nameplate; SHEET 1035-O 1.0
01E0016X0 70A0557 wheel hub; ZG270-500
00B0375J 00B0375 bolt; GB5783-86; M14×45-10.9-Zn.D; STL
01E0016X0 06B0214 Hardened washer; 14; 45
01E0016X0 76A0020 Gasket
01E0016X0 76A0019 snap ring
01E0016X0 70A0018 Internal gear; 40Cr
01E0016X0 70A0017 Planetary wheel carrier; QT450-10; 40B
01E0016X0 62A0024 Half shaft; 20CrMnTi
01E0016X0 61A0019 axis
01E0016X0 60A0121 Planetary gear shaft
01E0016X0 60A0011 Locating pin
01E0016X0 53A0064 cover
01E0016X0 52A0038 brake disc
01E0016X0 45C0004X1 clamp assembly; ordinary bridge
45C0004X1 12B0245 O-ring; GB3452.1-92; 20×1.8; YI9424
45C0004X1 56A0045 Washer; T2
45C0004X1 00A1965 pipe joint; 20
45C0004X1 00A0356 pipe joint bolt; 35
45C0004X1 71A0018 clamp; QT450-10
45C0004X1 61A0045 pin shaft
45C0004X1 53A0043 Upper cylinder head
45C0004X1 53A0042 Lower cylinder head
45C0004X1 50A0009 Piston
45C0004X1 35C0025 Friction pad assembly
45C0004X1 13B0108 Rectangular sealing ring; 69.2×79.2×4; EPDM
45C0004X1 13B0008 Dust ring; 63.5×94×13.6; rubber 1-1
45C0004X1 12B0481 O-ring seal; GB1235-76; 70×3.1; EPDM
45C0004X1 06B0002 Washer; GB93-87; 10; 65Mn
45C0004X1 05C0007 oil pipe assembly
45C0004X1 04B0027 Stop screw ZL50C.2.2-14
45C0004X1 03B0053 Nut; GB6170-86; M10-8-Zn.D; STL
45C0004X1 00B0019 bolt; GB5783-86; M10×30-8.8-Zn.D; STL
45C0004X1 00A0044 Vent nozzle
45C0004X1 00A0041 Vent nozzle seat
45C0004X1 00A0040 connector
01E0016X0 41C0018X1 Front axle main drive; 30E
41C0018X1 06B0013 Washer; GB93-87; 14; 65Mn
41C0018X1 00B0275 bolt; GB5783-86; M14×55-8.8-Zn.D; STL
41C0018X1 01B0036 Bolt; GB5783-86; M12×55-8.8-Zn.D; STL
41C0018X1 06B0008 Washer; GB93-87; 12; 65Mn
41C0018X1 34C1773 differential case; AGGL; 40B
41C0018X1 43A0136X0 Active spiral and large spiral bevel gear assembly; 20CrMnTiH5
41C0018X1 34C0608 lock nut; M33×1.5; assembly
41C0018X1 55A2553 shaft sleeve; h=16.41; 45
41C0018X1 81A0073 Gasket; green shell paper
41C0018X1 81A0037 gasket
41C0018X1 76A0011 Locking piece
41C0018X1 63A0031 cross shaft
41C0018X1 56A0075 Bevel gear gasket
41C0018X1 56A0042 Axle shaft gear gasket; 65Mn
41C0018X1 55A0218 bearing sleeve
41C0018X1 53A0308 Sealing cover
41C0018X1 44C0019 Thrust bolt
44C0019 55A0080 Copper sleeve
44C0019 01B0180 bolt; Q235
41C0018X1 43A0007 Axle shaft gear
41C0018X1 43A0006 Bevel gear
41C0018X1 41C0019X1 bracket assembly; 40B
41C0019X1 71A0026 bracket; QT42-10; 40B
41C0019X1 06B0270 Hardened washer; 45
41C0019X1 02B0032 Bolt GB32.1-88; M22×90-10.9-Zn.D
41C0018X1 40B0006 Iron wire φ1.5×450; Q235-A
41C0018X1 23B0018 Tapered roller bearing 31311; GB/T297-1994; 55×120×31.5
41C0018X1 23B0017 Tapered roller bearing 32215; GB/T297-1994; 75×130×33.25
41C0018X1 22B0001 Cylindrical roller bearing GB/T283-1994; 92606EK
41C0018X1 21A0040 Locking piece
