Description

24C0078 Electric lifting mechanism[ LIUGONG part

42E0020 Bottom guard plate assembly
00B0234 Bolt M20×50-10.9-Zn.D
06B0399 Washer 32060
00B0239 Bolt M12×40-10.9-Zn.D
06B0397 Washer 31232
14A5433 board
48D0293 cover
48D0149 cover
00D5898 cover
00D2970 cover
00B0238 Bolt M12×30-10.9-Zn.D

42E0014 Bottom guard plate assembly
06B0456 Washer
01B0327 bolt
48D0175 front bottom guard plate
00B0567 Bolt
60A1430 Bolt 175-54-23471
00D3419 bracket
36D0497 cover 175-54-C1270
03B1119 Nut
08B0032 pin
13A3113 board 24Y-50-00001
00B0386 Bolt
06B0397 Washer
48D0173 rear bottom guard plate
36D0496 cover 175-54-23220
00B0238 Bolt
36D0499 cover 24Y-50-01000

24C0553 Traction frame
02D2851 bracket
15A3385 pawl 09249-00016
02B0324 Bolt 01052-51260
03B1307 Nut 01592-11215
08B0193 pin
01B0671 bolt
06B0456 Washer
84A1298 plug
84A1301 plug

43C1228 001 Towing frame
00D3400 000 bracket
06B0015 001 Washer 16
03B0292 000 Nut M16-10-Zn.D
00B0210 000 Bolt M16×70-10.9-Zn.D
11D0673 000 Tow pin
17D0349 000 chain
00D3874 000 bracket
01B0629 000 bolt M33×80-10.9-Zn.D
06B0417 000 Washer 33380, 33
84A1297 000 Plug M20
84A1301 000 Plug M33

22C1558 Towing frame
02D7419 bracket
84A2309 Plug M39
84A1297 Plug M20
02D7420 bracket
02B0310 Bolt M39×3×90-Zn.D
06B0505 Washer 39
17D0829 Pin assembly
06B0012 Washer 16-140HV-Zn.D
00B0210 Bolt M16×70-10.9-Zn.D
18A2160 nut
60A3731 pin
08B0041 pin 8×80-Zn.D
03B0292 Nut M16-10-Zn.D
06B0015 Washer 16
