Description

13C0008X0 Brake assy for LIUGONG PART

13B0087 sealing ring; GB9877.1-88; FB85×110×12D; AGGL
12B0270 O-ring 51.5×5.3; YI9424
08B0032 Pin GB91-86; 6.3×60-Zn.D
06B0013 Washer; GB93-87; 14; 65Mn
04A0147 flange; 45
03B0406 Vent plug Z1/8 inch-27
03B0050 Slotted Nut
70A0120 bearing seat
62A0101 shaft; 20CrMnTi
56A0130 Washer; 45
00B0025 Bolt; GB5783-86; M14×35-8.8-Zn.D; STL
51C0267 Front drive shaft; assembly parts
06B0176 Washer; 45
01B0315 Bolt; GB5785-86; M12×1.5×65-10.9-Zn.D; STL
05E0318X1 Double variable system; ASSY
00C2819X1 Radiating pipe assembly; ASSY
72A0629 pressure plate; 45
06B0005 Washer; GB97.1-85; 8-140HV-Zn.D; STL
03B0661 Nut GB6170-86; M8-10-DK
10D6611 Steel pipe; WELD
11A7397 support plate; Q235
01B0465 Bolt; GB5782-86; M10×130-8.8-Zn.D; STL
00A5232 connector; 45
06B0006 Washer; GB93-87; 8; 65Mn
00B0019 Bolt; GB5783-86; M10×30-8.8-Zn.D; STL
07C4144 Hose assembly; ASSY
07C4145 Hose assembly; ASSY
00B0011 Bolt; GB5783-86; M12×25-8.8-Zn.D; STL
00B0052 Bolt; GB5783-86; M8×22-8.8-Zn.D; STL
06B0008 Washer; GB93-87; 12; 65Mn
29A4360 curved plate; Q235
32C0520 connector; 2-M42×2; ASSY
00B0085 Bolt; GB5783-86; M8×25-8.8-Zn.D; STL
06B0002 Washer; GB93-87; 10; 65Mn
00A4334 connector; CHSTL 50/35
06J0001 Washer; 45; AGGL
52C0168 Thermostat; ASSY
31C0173 connector; ASSY
73A0045 pipe clamp; 9; steel
12B0287 O-ring; GB3452.1-92; 36.5×3.55; YI9424
42C0861X1 Torque converter-gearbox installation; ASSY
34C2674 Filling pipe; ASSY
06B0006 Washer; GB93-87; 8; 65Mn
00B0102 Bolt; GB5783-86; M8×35-8.8-Zn.D; STL
07C0235 Fuel filler pipe assembly; assembly parts
10D2135 Filling pipe
12B0333 O-ring; GB3452.1-92; 31.5×2.65; YI9424
22C1370X1 right support; ASSY
03B0498 Lock nut; M18; assembly
35C0233 shock absorber (CB-1125-4)
13A1010 Gasket
01B0415 Bolt; GB5782-86; M18×120-10.9-Zn.D; STL
13A1011 Gasket
22C1369X1 left support; ASSY
03B0498 Lock nut; M18; assembly
13A1011 Gasket
13A1010 Gasket
01B0415 Bolt; GB5782-86; M18×120-10.9-Zn.D; STL
35C0233 shock absorber (CB-1125-4)
00C2776X1 oil filter line assembly; ASSY
31C0501 Right-angle connector; M45×2; ASSY
06B0002 Washer; GB93-87; 10; 65Mn
37B0010 Cable tie; nylon
07C4102 Hose assembly; ASSY
29A4828 Bent plate; Q235
07C4103 Hose assembly; ASSY
00B0012 Bolt; GB5783-86; M10×25-8.8-Zn.D; STL
07C4104 Hose assembly; ASSY
15Y0019X1 hydraulic system
00C3282 Distribution valve pipeline; ASSY
03B0652 Nut
72A0631 pressure plate; 45
12B0569 O-ring; 47.22×3.53; YI8435
01A0397 Connector block
12B0565 O-ring; 37.69×3.53; YI9424
09D0974 Steel pipe assembly; WELD
30C0260 connector; assembly parts
09C1568 pipe clamp; ASSY
31C0088 Elbow joint; ASSY
09C1559 Pipe clamp; ASSY
66C2029 Hose assembly; ASSY
66C2028 Hose assembly; ASSY
01A0617 flange joint; 45
12V0438 O-ring; 32.92×3.53; NBR
72A0628 pressure plate; 45
06B0008 Washer; GB93-87; 12; 65Mn
00B0019 Bolt; GB5783-86; M10×30-8.8-Zn.D; STL
00B0002 Bolt; GB5783-86; M10×35-8.8-Zn.D; STL
07C4957 Hose assembly; ASSY
00B0035 Bolt; GB5783-86; M12×35-8.8-Zn.D; STL
72A0010 pressure plate; ZG270-500
12C1968 Unloading valve; ASSY
12C0467 Unloading valve
30C0173 connector; assembly parts
44C0022 Pressure measuring connector; assembly parts
06B0002 Washer; GB93-87; 10; 65Mn
01B0435 Bolt; 45#
01A0441 connector
07C4976 Hose assembly; ASSY
66C2049 Hose assembly; ASSY
