Description

12C1196 Wheel Loader Spare Part combination valve Liugong

28 12B0302 000 O 形圈 O-RING 1
29 72A0003 000 压板 SPLIT FLANGE 1
30 00B0017 000 螺栓 BOLT 7
31 06B0008 000 垫圈 WASHER 28
32 11C0055 000 齿轮泵 GEAR PUMP 1
34 21C0046 000 液压油箱
HYDRAULIC OIL
TANK
1 Z
35 07C1116 001 软管总成 HOSE AS 1
36 12B0287 000 O 形圈 O-RING 3
37 72A0035 000 压板 SPLIT FLANGE 1
38 00B0019 000 螺栓 BOLT 4
39 72A0010 001 压板 SPLIT FLANGE 3
40 00B0035 000 螺栓 BOLT 12
41 31C0010 000 可调接头 CONNECTOR 1
42 12C1196 001 组合阀
COMBINATION
VALVE
1 Z
44 06B0007 000 垫圈 WASHER 2
45 31C0031 000 直角接头 CONNECTOR 1
46 10D0576 000 钢管总成 PIPE AS 1
47 00B0033 000 螺栓 BOLT 4
48 07C1117 000 软管总成 HOSE AS 1
49 06C0286 000 接动臂缸 Φ19 软管 HOSE 4
50 10D0589 000 钢管总成 PIPE AS 1
51 12C0057 000 单向阀 CHECK VALVE 1
52 10D2144 001 钢管总成 PIPE AS 1
53 06C3464 000 软管总成 HOSE AS 1
54 06B0006 000 垫圈 WASHER 26
55 00B0007 000 螺栓 BOLT 10
56 15B0064 001 管夹 CLAMP 5
57 00C0131 000 转斗大腔钢管 PIPE 1
58 10D2143 001 钢管总成 PIPE AS 1
59 12C1247 001 分配阀安装总成
CONTROL VALVE
MOUNTING
1 Z
60 06C0389 000 软管总成 HOSE AS 1
61 12B0342 000 O 形密封圈 O-RING 1
62 00A0541 000 管接头 CONNECTOR 1
63 10D2142 001 钢管总成 PIPE AS 2
64 12B0114 000 O 形圈 O-RING 4
65 04B0174 000 螺钉 SCREW 16
66 06C3465 000 软管总成 HOSE AS 1

1 27A0046 000 管夹 CLAMP 2
2 06B0002 000 垫圈 WASHER 10
3 00B0005 000 螺栓 BOLT 4
4 10D2502 钢管总成 PIPE AS 1
5 00B0029 000 螺栓 BOLT 2
6 03B0053 000 螺母 NUT 4
7 00B0019 000 螺栓 BOLT 2
8 10D3479 000 钢管总成 TUBE AS 1
9 03B0093 002 螺塞 PLUG 2
10 12B0351 000 O 形密封圈 O-RING 2
11 10D2853 钢管总成
TUBE
1
12 10D2503 钢管总成 PIPE AS 1
13 27A0290 000 管夹 CLAMP 2
14 23A4904 000 弯板 PLATE 1
15 23A4893 弯板 PLATE 1
16 44C0022 000 测压接头 JOINT 1
