Description

12B0250 o-ring 37.5×3.55 for LIUGONG part

09C0466 83A0633 Rubber ring; YI6364
09C0466 00B0035 Bolt; GB5783-86; M12×35-8.8-Zn.D; STL
09C0466 06B0008 Washer; GB93-87; 12; 65Mn
00C1864 07C2811 Hose assembly; ASSY
00C1864 07C2812 Hose assembly; ASSY
15E0844X1 00C1850 Distribution valve pipeline; ASSY
00C1850 12B0292 O-ring; GB3452.1-92; 21.2×1.8; YI9424
00C1850 00B0035 Bolt; GB5783-86; M12×35-8.8-Zn.D; STL
00C1850 04A1244 flange; 35
00C1850 01B0103 Bolt; GB5782-86; M12×80-8.8-Zn.D; STL
00C1850 04A0215 Method flange; Q235
00C1850 01B0010 Bolt; GB5782-86; M12×60-8.8-Zn.D; STL
00C1850 44C0042 Distribution valve installation assembly; assembly parts
44C0042 06B0008 Washer; GB93-87; 12; 65Mn
44C0042 12C0090 Distribution valve
44C0042 31C0034 Adjustable joint; assembly parts
31C0034 12B0343 O-ring seal; GB1235-76; 18×2.4; YI9424
31C0034 31C0034X0 adjustable connector
31C0034 12B0284 O-ring; GB3452.1-92; 7.5×1.8; YI9424
44C0042 06B0007 Washer; GB97.1-85; 12-140HV-Zn.D; STL
44C0042 00B0058 bolt; GB5783-86; M12×45-8.8-Zn.D; STL
00C1850 06B0008 Washer; GB93-87; 12; 65Mn
00C1850 12B0268 O-ring; ISO 3601-1.2002; 47.5×3.55; NBR-90
00C1850 07C2803 Hose assembly; ASSY
00C1850 12B0302 O-ring; GB3452.1-92; 46.2×3.55; YI9424
00C1850 01B0142 Bolt; GB5782-86; M12×90-8.8-Zn.D; STL
00C1850 04A0882 flange
00C1850 09C0709 pipe clamp; ASSY
09C0709 09C0056 pipe clamp; ASSY
09C0056 21A0180 Lower pipe clamp; Q235
09C0056 21A0181 Upper pipe clamp; Q235
09C0056 83A0070 Rubber ring; Rubber I-1
09C0056 06B0008 Washer; GB93-87; 12; 65Mn
09C0056 00B0013 Bolt; GB5783-86; M12×40-8.8-Zn.D; STL
09C0709 09C0069 pipe clamp; fitting
09C0069 21A0942 Upper pipe clamp; Q235
09C0069 21A0943 Lower pipe clamp; Q235
09C0069 83A0122 Rubber ring; YI6364
09C0069 06B0008 Washer; GB93-87; 12; 65Mn
09C0069 00B0035 Bolt; GB5783-86; M12×35-8.8-Zn.D; STL
09C0709 00D4273 mounting plate; WELD
00C1850 06B0007 Washer; GB97.1-85; 12-140HV-Zn.D; STL
00C1850 09C0569 pipe clamp; ASSY
09C0569 21A1275 Lower pipe clamp; Q235
09C0569 00B0011 Bolt; GB5783-86; M12×25-8.8-Zn.D; STL
09C0569 06B0008 Washer; GB93-87; 12; 65Mn
09C0569 83A0209 Rubber ring; YI6364
09C0569 21A1274 Upper pipe clamp; Q235
00C1850 06B0002 Washer; GB93-87; 10; 65Mn
00C1850 00B0019 Bolt; GB5783-86; M10×30-8.8-Zn.D; STL
00C1850 72A0630 pressure plate; 45
00C1850 72A0628 pressure plate; 45
00C1850 09C0056 pipe clamp; ASSY
09C0056 21A0180 Lower pipe clamp; Q235
09C0056 21A0181 Upper pipe clamp; Q235
09C0056 83A0070 Rubber ring; Rubber I-1
09C0056 06B0008 Washer; GB93-87; 12; 65Mn
09C0056 00B0013 Bolt; GB5783-86; M12×40-8.8-Zn.D; STL
00C1850 12B0287 O-ring; GB3452.1-92; 36.5×3.55; YI9424
00C1850 07C1240 Hose assembly; ASSY
00C1850 12B0294 O-ring; GB3452.1-92; 32.5×3.55; YI9424
00C1850 12B0250 O-ring; GB3452.1-92; 37.5×3.55; YI9424
00C1850 00B0033 Bolt; GB5782-86; M12×70-8.8-Zn.D; STL
00C1850 72A0631 pressure plate; 45
00C1850 04A1782 flange; 45
00C1850 44C0022 Pressure measuring connector; assembly parts
15E0844X1 00C1863 Pilot control line; ASSY
00C1863 12B0284 O-ring; GB3452.1-92; 7.5×1.8; YI9424
00C1863 06C7514 Hose assembly; ASSY
00C1863 06C7515 Hose assembly; ASSY
00C1863 05C3487 Hose assembly; ASSY
00C1863 44C0071 Pilot switch; assembly parts
44C0071 03B0036 Nut; GB6170-86; M6-8-Zn.D; STL
44C0071 11A0683 mounting plate; Q235
44C0071 06B0117 Washer; 14; AGGL
44C0071 06B0024 Washer; GB97.1-85; 6-140HV-Zn.D; STL
44C0071 06B0003 Washer; GB93-87; 6; 65Mn
44C0071 03B0180 Nut; GB6173-86; M14×1.5-05-Zn.D; STL
44C0071 12B0284 O-ring; GB3452.1-92; 7.5×1.8; YI9424
44C0071 00B0010 Bolt; GB5783-86; M6×20-8.8-Zn.D; STL
44C0071 83A0136 Guard ring; Industrial offset A
44C0071 21A1329 mounting plate; Q235
44C0071 16D0454 Joystick; welded parts
44C0071 12C0174 Ball valve; ASSY
44C0071 00A0787 connector
00C1863 12C2667 Pilot valve installation assembly; ASSY
12C2667 12B0351 O-ring seal; GB1235-76; 16×2.4; YI9424
12C2667 00B0010 Bolt; GB5783-86; M6×20-8.8-Zn.D; STL
12C2667 03B0036 Nut; GB6170-86; M6-8-Zn.D; STL
12C2667 12C0458 Pilot valve
12C2667 06B0006 Washer; GB93-87; 8; 65Mn
12C2667 04B0218 screw; GB818-85; M8×16-4.8-Zn.D; STL
12C2667 06B0003 Washer; GB93-87; 6; 65Mn
12C2667 12B0285 O-ring; GB3452.1-92; 10.6×1.8; YI9424
12C2667 10A2508 Washer; ST12
12C2667 12B0284 O-ring; GB3452.1-92; 7.5×1.8; YI9424
12C2667 00A0256 connector
12C2667 10A2150 mounting plate
12C2667 00A0257 connector; 35#
00C1863 05C3913 Hose assembly; ASSY
00C1863 06C6664 Hose assembly; ASSY
00C1863 05C3484 Hose assembly; ASSY
00C1863 05C3485 hose assembly; ASSY
