CLG842 11E0049 分配阀管路 Distributing Valve Pipeline (高原机用 Applies to Mashine in Plateau)

1 72A0003 ZL50C.9.12-1 压板 Pressboard 1
2 00B0035 GB5783-86 螺栓 Bolt M12×35-8.8-Zn.D 16
3 06B0008 GB93-87 垫圈 Washer 12 16
4 07C0091 软管总成 Hose assembly 1
5 12B0019 GB3452.1-92 O形圈 O-ring 46.2×3.55 2
6 12B0102 GB3452.1-92 O形圈 O-ring 36.5×3.55 4
7 07C0092 软管总成 Hose assembly 1
8 17D0050 管夹总成 Pipe clamp assembly 1
9 23A1184 弯板 Bent plate 1
10 03B0400 GB6170-86 螺母 Nut M10-8-Zn.D 4
11 06B0001 GB97.1-85 垫圈 Washer 10-140HV-Zn.D 6
12 00B0019 GB5783-86 螺栓 Bolt M10×30-8.8-Zn.D 12
13 06B0002 GB93-87 垫圈 Washer 10 12
14 17D0049 管夹总成 Pipe clamp assembly 1
15 10D0598 钢管总成 Steel pipe assembly 1
16 72A0010 ZL50C.10.4-6 压板 Pressboard 3

17 10D0625 钢管总成 Steel pipe assembly 1
18 72A0035 ZL50C.10.9-1 压板 Pressboard 1
19 72A0041 ZL50C.10,21-1 压板 Pressboard 1
20 00B0025 GB5783-86 螺栓 Bolt M14X1.5-8.8-Zn.D 4
21 06B0013 GB93-87 垫圈 Washer 14 4
22 44C0022 SMK20-M14X1.5-PC 测压接头 Pressure measuring joint 1
