LW500F 双变系统 9103581 Transmission System

1 5003040 接头 Joint 2
2 5004084 直角组合接头 Hose 1
3 9366714 软管总成 Hose 1
4 9366715 软管总成 Hose 1
5 9345093 弯管 Bent Pipe 1
6 5004081 接头 Joint 2
7 9345097 胶管总成 Hose 2
8 9300515 垫 Seal Washer 1
9 4102456 螺柱 AM10X1X20 Bolt 12 GB899-88
10 4401008 垫圈 10 Washer 16 GB93-87
11 4302002 螺母 M10X1 Nut 12 GB6171-86
12 4005070 螺栓 M12X45 Bolt 12 GB5783-86
13 4401009 垫圈 12 Washer 14 GB93-87
14 5004958 接头 Joint 4
15 9367621 变速箱总成 Transmission 1
16 9369473 减震器组件 Absorber 2
17 9369482 支架 Support 2
18 9302637 垫圈 Washer 2
19 4004100 螺栓 M20x180 Bolt 2 GB5782-86
20 4303014 螺母 M20 Nut 2 GB6172-86
21 4005108 螺栓 M18x40 Bolt 8 GB5783-86
22 4401012 垫圈 18 Washer 8 GB93-87
23 4681041 胶管 B 45X420 Hose 1 JB/T8406-2001
24 5004833 分离式法兰 Split Flange Clamp 1
25 4005054 螺栓 M10x30 Bolt 4 GB5783-86

26 9310487 加油管 Oil Pipe 1
27 4801076 O 形圈 45×3.5 O-Ring 1 GB1235-76
28 9367406 支架 Support 1
29 9300935 软管 Pipe 1
30 9300932 直角接头 Joint 1
31 4A06004 喉箍 16-25 Hose Clamp 2 QC/T619-1999
32 9300584 滤清器 Filter 1
33 4005044 螺栓 M8X40 Bolt 2 GB5783-86
34 4404008 垫圈 8 Washer 2 GB97.1-85
35 4401007 垫圈 8 Washer 2 GB93-87
36 4301008 螺母 M8 Nut 2 GB6170-86
