推臂总成 Push arm group

1 O 形圈 140×3.55 O-ring 140×3.55 B160131401 GB/T3452.1-2005 2
2 推臂固定座 Push arm fixing seat TD16005029 2
3 垫圈 16 Washer 16 GB/T97.1-2002 24
4 螺栓 M16×110-10.9 Bolt M16×110-10.9 B040860020 GB/T5782-2000 24
5 螺栓 M20×130-10.9 Bolt M20×130-10.9 B040860009 GB/T5782-2000 4
6 垫圈 20-300HV Washer 20-300HV B060462003 GB/T97.1-2002 4
7 四方螺母 28.6×28.6×M20 Nut TD16005043 GB/T1229-1991 4
8 联接盖 The coupling cover TD16005025 2
9 调整垫片 Trimmed gasket TD16005032 40
10 挡圈 105 Snap ring B070151053 GB/T893.1-1986 2
11 关节轴承 GEG60ES Joint bearing GEG60ES B120516063 GB/T9163-2001 4
12 调整支撑组件 Adjust the support TD16101009 1
13 左推臂组件 Left push arm assembly TD16005002 1
14 螺母 M20 Nut M20 B050332018 GB/T6170-2000 6
15 垫圈 Bolt Z5B065057 6
16 联接座 The connecting seat TD16005028 1

17 螺栓 M20×110 Bolt M20×110 B040810003 GB/T5782-2000 6
18 右推臂组件 Push right arm assembly TD16005001 1
19 螺栓 M10×55 Bolt M10×55 B040811055 GB/T5782-2000 2
20 销轴 Pin TD16005033 2
21 螺母 M10 Nut M10 B050331008 GB/T6170-2000 2
22 隔套 I Spacer I TD16005044 2
23 油杯 M10×1 Oil cup M10×1 B150101000 JB/T7940.1-1995 1
24 密封橡胶 Sealing rubber TD22004013
