937.11 紧急制动系统 Emergency Brake Syste

1 Z30E11F-3 1 铰接螺栓 Bolt 1
2 B-G000910-00018 1 销 2×16ZnD Pin 1
3 Z30E.11-7 1 调节片 Pad 6
4 W-18-00025 1 驻车制动气室|CL30-3507002 Brake chamber 1
5 W-13-00018 1 气管|DH/G18(L=1100) Pipe 1
6 B-J010020-00002 1 垫圈 12 Washer 1
7 B-Q020710-00018 1 O 形圈 14×2.4 O-ring 8
8 Z30E.11-1 1 直角接头 Joint 1
9 B-Q020710-00098 1 O 形圈 8×1.9 O-ring 2
10 W-18-00015 1 手控制动阀 QZ50-3526002 Control valve 1
11 Z30E.11-3 1 直角接头 Joint 2
12 Z30E.11F-1 1 直角接头 Joint 1
13 W-13-00006 1 气管|DH/G12×1.25(L=1600) Pipe 1
14 W-13-00102 1 气管|DH/G90x18x1.5(L=1600) Pipe 1
15 Z30E.11F-2 1 接头 Joint 1
16 B-G057830-00001 1 螺栓 M10×16ZnD Bolt 1
17 B-G000930-00001 1 垫圈 10 Washer 1
18 B-G00097B-00002 1 垫圈 10ZnD Washer 1
19 Z30E.11F.2 1 三通接头 Joint 1
20 B-J010020-00007 1 垫圈 22 Washer 2
21 W-18-00011 1 气控截止阀|QZ50-3516001 Stop valve 1
22 Z30E.11-5 1 接头 Joint 1
23 B-Q020710-00023 1 O 形圈 16×2.4 O-ring 1
24 W-13-00038 1 气管|DH/G16(L=800) Pipe 1
25 B-Q020710-00006 1 O 形圈 11×1.9 O-ring 3
26 Z30E.11-8 1 紫铜垫 Washer 3
27 Z30E.9F.3 1 储气筒至三通管路 Pipe 1
28 Z30.9.4-1 1 接头 Joint 1
29 B-J010020-00005 1 垫圈 18 Washer 1
30 Z30E.11-2 1 接头 Joint 2
31 W-18-00020 1 双向换通阀 JN560-3527030A Valve 1
32 937.11.1 1 直角接头 Joint 1
