CLG906C 10C0424 002 斗杆油缸总成 ARM CYLINDER AS

01 13B0479 000 防尘圈 DUST RING 4 N1 13B0805
01 13B0805 000 防尘圈 DUST RING 4
02 55A1418 000 A 型轴套 BUSHING 2 N1 55A3305
02 55A3305 000 轴套 BUSHING 2
03 10B0018 000 油杯 GREASE FITTING 1 N1 10B0014
03 10B0014 000 油杯 FITTING 1
04 14D0100 000 活塞杆 PISTON ROD 1
05 76A0238 000 O 形圈挡圈 BACKUP RING 2
06 80A0252 000 O 形密封圈 O-RING 1
07 83A0494 000 纳污环 WIPER RING 2
08 13B0461 000 导向环 GUIDE RING 2
09 80A0248 000 孔用密封圈 SEAL RING 1
10 50A0177 000 活塞 PISTON 1
11 55A1427 000 缓冲套 CUSHION COLLAR 1
12 76A0210 000 挡圈 SNAP RING 1
13 55A1419 000 缓冲环 BUFFERING RING 1
14 76A0211 000 卡环 SNAP RING 1
15 20B0051 000 钢球 STEEL BALL 1
16 04B0733 000 螺钉 SCREW 1
17 76A0201 000 挡圈 SNAP RING 1
18 13B0478 000 防尘圈 DUST RING 1
19 55A1644 000 缓冲套 D90/55 CUSHION COLLAR 1
19 76A0200 挡圈 SNAP RING 1
20 80A0267 000 轴用密封圈 SEAL RING 1
21 80A0266 000 缓冲圈 BUFFERING RING 1
22 55A1417 000 导向套 GUIDE SLEEVE 1
23 76A0199 000 钢丝挡圈 SNAP RING 1
24 55A3362 000 导向套 GUIDE SEELVE 1
24 53A0534 端盖 COVER 1
25 12B0779 000 O 形圈 O-RING 1
26 80A0247 000 O 形圈挡圈 BACKUP RING 1
27 80A0258 000 O 形密封圈 O-RING 1
28 13D0291 000 缸体组件 CYLINDER BODY 1 N1 13D0564
28 13D0564 000 缸体 CYLINDER BODY 1
29 10D2827 000 钢管组件 PIPE GP 1
30 27A0625 000 卡箍 CLIP 1
31 00B0007 000 螺栓 BOLT 1
