Description
Z510210400 Nut
1 挡圈 190 Retainer190 B070150001 GB893.1-86 1
2 挡圈 80 Retainer80 B070158003 GB893.1-86 2
3 挡圈 110 Retainer110 B070250001 GB894.1-86 1
4 挡圈 50 Retainer50 B070255002 GB894.1-86 1
5 开口销 6.3×55 Cotter pin6.3×55 B080210027 GB/T91-2000 1
6 轴承 208 Bearing 208 B120124018 GB/T276-1994 2
7 轴承 2222E Bearing 2222E B120320001 GB/T283-1994 1
8 钢球φ5 Steel ball φ5 B120710500 GB/T308-2002 1
9 齿轮 Gear Z510210090 1
10 离合器轴(Ⅱ、Ⅳ) Clutch shaft (Ⅱ、Ⅳ) Z510210100 1
11 垫片 Gasket Z510210250 1
12 密封环 Ring seal Z510210310 1
13 压板 Clamping plate Z510210390 1
14 螺母(M36×1.5) Nut (M36×1.5) Z510210400 1
15 活塞 Piston Z510210440 1
16 活塞外封环 Piston outer seal ring Z510210450 1
17 压板 Clamping plate Z510210470 1
18 挡环 Snap ring Z510210500 1
19 单向阀座 Check valve seat Z510210520 1
20 离合器主动片 Clutch driving disc Z510210560 6
21 弹簧 Spring Z51021158 1
22 弹簧座 Spring Retainer Z51021159 1
23 齿轮 Gear Z51021162 1
24 齿轮套 Gear sleeve Z51021163 1
25 离合器被动片 Clutch driven disc Z510210460 5
离合器（Ⅱ Ⅳ） Clutch（Ⅱ Ⅳ） NZ51021060010
1 前驱动桥(美驰) Xuzhou front axle W046500000
（ 18MRF-
C216BR） 1
2 双头螺柱 Double thread stud Z420100060 8
3 螺母 M16×1.5 Nut M16X1.5 B050411614 28
4 垫圈 16 Washer 16 B060111604 28
5 后传动轴 Rear drive shaft Z5B05900100 1
6 主传动轴用螺栓 Main drive shaft bolt Z420100040 8
7 螺母 M14×1.5 Nut M14X1.5 B050411412 12
8 垫圈 14 Washer 14 B060111404 16
9 传动轴主 Main drive shaft W041100000 ZL50D.19 1
10 后驱动桥(美驰) Xuzhou rear axle W046600000
（ 18MRF-
C216BS） 1
11 后传动轴用螺栓 Rear drive shaft bolt Z420100020 4
12 后桥过渡盘 Rear axle connection plate Z420100030 1
13 后桥过渡盘用螺栓 Rear axle plate bolt Z420100010 4
14 前传动轴 Front drive shaft Z5B05900200 1
15 螺栓 M14×1.5×35 Bolt M14X35 B041111435 4
16 螺栓 Bolt Z420100050 8
1 轮边减速器总成 Wheel-end reduction W046500001 83310600 2
2 轮辋螺母(左旋) Wheel rim Nut (L) W041400651 80041003 12
3 轮辋螺栓(左旋) Wheel rim Bolt (L) W041400651 75502324 12
4 制动器总成 Brake assembly W041200000 84741300 4
5 桥壳总成 Housing assembly W046503000 91110023 1
6 螺塞 M24×1.5 Plug M24×1.5 W041400941 75500197 2
7 组合密封垫 Gasket B060802403 53200005 2
8 螺栓 M14×1.5×60 Bolt M14×1.5×60 B041011460 50011012 2
9 通气塞 Plug W041400931 56100001 1
10 半轴 Axle shaft W041400221 79000142 2
11 轮辋螺栓 M22X1.5X90 Wheel rim Bolt M22X1.5X90 W041400652 75502318 12
12 轮辋螺母 22X1.5 Wheel rim Nut 22X1.5 W041400652 80041001 12
13 螺栓 Bolt 14X1.5X35 Bolt 14X1.5X35 B041111435 50012017 10
14 主减速器总成(前桥) Main reducer W041400701 82310500 1
15 垫圈 14 Washer 14 B060111404 52020005 14
16 螺栓 M14×1.5×40 Bolt M14×1.5×40 B041111440 50012019 2
17 销 A12×20 Pin A12×20 B080111220 51270005 3
18 防尘罩 Dust boot W046505000 80303004 2
19 垫圈 10 Washer 10 B060411002 52000002 8
20 垫圈 10 Washer 10 B060111003 52020003 8
21 螺栓 M10X20 Bolt M10X20 B040911020 50009011 8
1 轮边减速器总成 Wheel-end reduction W046500001 83640300 2
2 轮辋螺栓 M22X1.5X90 Wheel rim bolt M22X1.5X90 W041400652 75502318 12
3 轮辋螺母 22X1.5 Wheel rim Nut 22X1.5 W041400652 80041001 12
4 单钳盘制动器总成 Brake caliper assembly W041200000 72006035 2
5 桥壳总成 Housing assembly W046503000 91110023 1
6 螺塞 M24X1.5 Plug M24X1.5 W041400941 75500197 2
7 组合密封垫 Compound seal B060802403 53200005 2
8 通气塞 Z1/8 ″ Plug W041400931 56100001 1
9 半轴 Axle shaft W041400221 79000142 2
10 轮辋螺栓 Bolt Rim bolt W041400651 75502324 12 M22X1.5LHX90
11 轮辋螺母 Rim nut W041400651 80041003 12 M22X1.5LH
12 垫圈 14 Washer 14 B060111404 52020005 14
13 螺栓 Bolt 14X1.5X35 B041111435 50012017 10
14 主减速器总成 Carrier assembly W041500011 82311600 1
15 螺栓 M14×1.5×40 Bolt M14×1.5×40 B041111440 50012019 2
16 螺栓 Bolt B041011460 50011012 2 M14x1.5×60
17 销 Pin B080111220 51270005 3
