Description

SP101364 cylinder head cover for LIUGONG part

06B0066 Washer GB97.1-85; 5-140HV-Zn.D
60A1149 pin GB91-86; 2×12-Zn.D
08B0194 pin shaft GB882-86 ;B5×20
03H2026 Connecting rod joint (1) 30CD730002
03H2007 connector; 35
03B0053 Nut GB6170-86; M10-8-Zn.D
64H2009 connecting rod 30CD730001
03V0420 Nut GB6170-86; M10-8-Zn.D/left GB6170-86; M10-8-Zn.D left
03H2027 Connecting rod joint (2) 30CD730003
08B0004 pin GB91-86; 3.2×20-Zn.D
06B0005 Washer GB97.1-85; 8-140HV-Zn.D
08B0006 pin shaft GB882-86 ;B8×28
22A3848 Bent plate
55A2926 positioning sleeve
03B0227 Nut GB6171-86; M12×1.5-8-Zn.D
86A0885 handle
06B0007 Washer GB97.1-85; 12-140HV-Zn.D
11D0511 pin shaft
16D0875 rod assembly
55H2020 oil-free bushing 1225
12C2247 Triple multi-way valve CDB2-F15-03
12B0339 O-ring GB1235-76; 24×2.4; YI9424
30C1518 connector
12B0284 0-ring GB3452.1-92; 7.5X1.8
74A2267 Side shift control sign
06B0053 Washer 22 JB982-77
55H2020 oil-free bushing 1225

32E0824 Door frame system 1 CPC20, CPC25, CPCD20, CPCD25
43C1337 Fork frame assembly 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
Gantry hydraulic system 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
10K2038 Lifting cylinder 2 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
06C3276 Hose assembly 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
30H2031 Low pressure hose 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
37J2003 Nylon cable tie 8 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
15J2011 stainless steel clamp 12～20 6 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
30H2029 Low pressure hose 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
10C0587 Center cylinder 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
12B0370 O-ring GB3452.1-92 15×1.8 5 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
52A0376 Fixing nut 3 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
12B0339 O-ring seal GB1235-76 24×2.4 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
06C3277 Hose assembly 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
12C2196 Speed ​​limiting valve 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
15D0555 Four-way connector 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
10C0630 Tilt cylinder 2 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
10B0014 Oil cup GB1152-89 M10×1 4 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
00B0007 Bolt GB5783-86 M8×16-8.8-Zn.D 4 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
11L2001 Tilt cylinder pin 4 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
06B0006 Washer GB93-87 8 6 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
06C5138 Hose assembly 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
06C3278 Hose assembly 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
16A3599 Fixed block 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
00B0070 Bolt GB5783-86 M8×45-8.8-Zn.D 2 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
20A5571 Pipe clamp 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
30H2028 Low pressure hose 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
02A0634 Tee connector 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
10D3440 steel pipe assembly 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
00A2367 Connector 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
12B0291 O-ring seal GB1235-76 22×2.4 3 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
00A2368 Connector 2 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
12B0285 O-ring GB3452.1-92 10.6×1.8 12 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
02D2097 Four-way base 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
05C1484 Hose assembly 2 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
05C1483 Hose assembly 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
05C1482 Hose assembly 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
03B0149 Nut GB6171-86 M18×1.5-8-Zn.D 6 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
00A3609 Threaded connection 2 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
12A1831 Tubing fixing plate 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
16A3581 Tubing holder 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
05C1439 Hose assembly 2 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
00A2436 Connector 8 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
00D2636 Four-way base 1 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
00B0012 Bolt GB5783-86 M10×25-8.8-Zn.D 4 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
06B0002 Washer GB93-87 10 4 CPC20, CPC25, CPCD20, CPCD25/CPD20, CPD25
Block shelf assembly; ASSY
23L2049 Block shelf; welding parts 1 CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
00B0342 Bolt; GB5786-86; M14×1.5×35-8.8-Zn.D; STL 8 CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
06B0009 Washer; GB97.1-85; 14-140HV-Zn.D; STL 8 CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
06B0013 Washer; GB93-87; 14; 65Mn 8 CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
To
Side shifter (domestic) 1 Optional CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
12B0380 O-ring seal GB1235-76 14×2.4 2 Optional CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
06C3937 Hose assembly 1 Optional CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
43C1631 Sideshifter 1 Optional CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
06C3936 Hose assembly 1 Optional CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
Side shifter (Cascade) 1 Optional CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
06C3937 Hose assembly 1 Optional CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
12B0380 O-ring seal GB1235-76 14×2.4 2 Optional CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
06C3936 Hose assembly 1 Optional CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
43C0847 Sideshifter 1 Optional CPC20, CPCD20, CPC25, CPCD25/CPD20, CPD25
