Description

LG853.07.22 60301000058 CBGJ2100 gear pump for LONKING parts

1 CDM6210.08.10-01 HOSE SLEEVE 胶管护套 4
2 CDM6210.08.011 HOSE ASSEMBLY 软管总成 2
3 CDM6210.08.012 HOSE ASSEMBLY 软管总成 2
4 CDM6210.08.013 HOSE ASSEMBLY 软管总成 2
5 CDM6210.08.014 HOSE ASSEMBLY 软管总成 2

1 CDM6210.14.516 F OIL PORT CONNECTOR F 油口接头 1
2 CDM6210.14.034 HOSE ASSEMBLY 软管总成 1
3 CDM6210.14.514 STRAIGHT CONNECTOR 直通接头 1
4 CDM6210.14.533 THREE-WAY CONNECTOR 三通接头 1
5 F481CACF222212-1600 HOSE ASSEMBLY 软管总成 1
6 CDM6210.14.05-02 R2 OIL RETURN CHANNEL BLOCK R2 口回油油路块 1
7 CDM6210.14.036 HOSE ASSEMBLY 软管总成 1
8 LV-12-45T CHECK VALVE4.5 单向阀 4.5 1
9 CDM6210.14.552 FLANGE COMPONENT 法兰组件 6
10 CDM6210.14.037 HOSE ASSEMBLY 软管总成 2
11 CDM6210.14.038 HOSE ASSEMBLY 软管总成 2
12 CDM6210.14.03.16 PRESSURE PIPE D27 压力管 D27 1
CDM6210.14.03.18 PRESSURE PIPE D27 压力管 D27 1
13 CDM6210.14.553 FLANGE COMPONENT 法兰组件 2
14 F481CACF222212-820 HOSE ASSEMBLY 软管总成 1
15 CDM6210.14.509 STRAIGHT CONNECTOR 直通接头 2
16 CDM6210.14.040 HOSE ASSEMBLY 软管总成 4
17 EW22LOMDA3C STRAIGHT CONNECTOR 直角接头 1
18 GE22LR1 1/4EDOMDA3C STRAIGHT CONNECTOR 直通接头 2
19 GB/T5783 BOLT M8×20 螺栓 M8×20 3
20 GB/T97.1 WASHER 8 垫圈 8 3
21 GB/T5783 BOLT M12×30 螺栓 M12×30 2
22 GB/T97.1 WASHER 12 垫圈 12 6
23 CDM6210.14.07-02 BRACKET 支架 1
24 MFP160 AGE10 OIL FILTER 滤油器 1
25 CDM6210.14.03.05 PUMP CONNECTING PIPE 泵接管 1
26 HG4-761 OIL SUCTION PIPE Φ89×278 吸油管Φ89×278 1
27 TBH103 HOSE HOOP 软管箍 4
28 CDM6210.14.03.04 OIL RADIATOR OIL OUTLET PIPE 油散出油管 1
29 CDM6210.14.03.03 OIL RADIATOR OIL INLET PIPE 油散进油管 1
30 CDM6210.14.07.01 BRACKET 支架 1
31 CDM6210.14.06-02 PIPE CLAMP D42-48 管夹 D42-48 1
32 LV-12-25T CHECK VALVE 2.5 单向阀 2.5 1
33 MAIN PUMP 主泵 1
34 CDM6210.14.042 HOSE 软管 1
35 CDM6210.14.041 HOSE 软管 1
36 CDM6210.14.510 STRAIGHT CONNECTOR 直通接头 1
37 MAIN VALVE 主控阀 1
38 CDM6210.14.01 MAIN VALVE SEAT 主阀座 1

39 CDM6210.14.043 HOSE 软管 1
40 SWING DRIVE ASSEMBLY 回转驱动总成 1
41 O-RING Ф69.44×3.53 O 形圈Ф69.44×3.53 1
42 GB/T70.1 BOLT M12×25 螺钉 M12×25 4
43 M1600-150-0350 PIPE CLAMP 管夹 1
44 M1600-125-0325 PIPE CLAMP 管夹 1

1 CDM6210.14.05-07 R2 OIL RETURN PORT PRESS PLATE R2 回油口压板 1
2 O-RING Ф32.92×3.53 O 形圈Ф32.92×3.53 1
3 CDM6210.14.05-08 R2 BYPASS OIL PORT PRESS PLATE R2 旁通油口压板 1
4 O-RING Ф32.92×3.53 O 形圈Ф32.92×3.53 1
5 805601230 OIL RETURN BYPASS VALVE 回油旁通阀 1
6 O-RING Ф18.64×3.55 O 形圈Ф18.64×3.55 1
7 GE22LREDOMDA3C STRAIGHT CONNECTOR 直通接头 2
8 GB/T5782 BOLT M8×65 螺栓 M8×65 4
9 F481CFCF222212-800-0° HOSE 软管 1
10 CDM6210.14.573 PLUG G1/4 堵头 G1/4 1
11 GB/T70.1 BOLT M10×25 螺钉 M10×25 4
12 GB/T97.1 WASHER 10 垫圈 10 4
13 GB/T5783 BOLT M8×20 螺钉 M8×20 4
14 GB/T97.1 WASHER 8 垫圈 8 4
