Description

LG843.10Ⅰ.02 Rear frame CDM843 parts

1 W-08-00097 水箱散热器总成 Radiator 1
2 B-Q020490-00001 垫圈10 Washer 4
3 B-G057820-00015 螺栓M10×50ZnD Bolt 2
4 WZ30.1.1 水箱减振垫 Insulator 2
5 WZ30.1.8 附水箱 Reservoir 1
6 B-G057830-00139 螺栓M8×20ZnD Bolt 2
7 B-G000930-00017 垫圈8 Washer 4
8 B-G00097B-00023 垫圈8ZnD Washer 4
9 B-G061700-00036 螺母M8ZnD Nut 4
10 WZ30.1-14 垫 Spacer 2
11 WZ30.1-4 支架 Bracket 1
12 B-G057830-00006 螺栓M10x25ZnD Bolt 2
13 B-G00097B-00002 垫圈10ZnD Washer 2
14 B-G000930-00001 垫圈10 Washer 2
15 WZ30.1-1 垫 Plat 2
16 WZ30C.1B-1 柴油机出水管 Hose 1
17 B-J088700-00019 喉箍d80 Clamp 4
18 WZ30C.1B-3 柴油机进水接管 Hose 1
19 WZ30C.1B-6 排气管Φ8×1000 Pipe 1
20 B-J088700-000215 喉箍d12 Clamp 2
