Description
41A0001 Internal gear ring for liugong spare part
45C0004X1 61A0045 pin shaft
45C0004X1 53A0043 Upper cylinder head
45C0004X1 53A0042 Lower cylinder head
45C0004X1 50A0009 Piston
45C0004X1 35C0025 Friction pad assembly
45C0004X1 13B0108 Rectangular sealing ring; 69.2×79.2×4; EPDM
45C0004X1 13B0008 Dust ring; 63.5×94×13.6; rubber 1-1
45C0004X1 12B0481 O-ring seal; GB1235-76; 70×3.1; EPDM
45C0004X1 06B0002 Washer; GB93-87; 10; 65Mn
45C0004X1 05C0007 oil pipe assembly
45C0004X1 04B0027 Stop screw ZL50C.2.2-14
45C0004X1 03B0053 Nut; GB6170-86; M10-8-Zn.D; STL
45C0004X1 00B0019 bolt; GB5783-86; M10×30-8.8-Zn.D; STL
45C0004X1 00A0044 Vent nozzle
45C0004X1 00A0041 Vent nozzle seat
45C0004X1 00A0040 connector
01E0080X0 41A0078 Planetary gear
01E0080X0 41A0077 Sun wheel
01E0080X0 41A0076 Internal gear; 40Cr
01E0080X0 35C0047 sealing ring
01E0080X0 27A0052 Dust cover
01E0080X0 23B0046 Tapered roller bearing GB/T297-1994; 100×150×32
01E0080X0 23B0045 Tapered roller bearing 32219; GB/T297-1994; 95×170×45.5
01E0080X0 20B0042 Needle roller 4×45.5
01E0080X0 20B0037 steel ball GB308-89;
01E0080X0 20A2273 Gasket
01E0080X0 15A0049 fixed block
01E0080X0 13B0251 front and rear axle shoe oil seal
01E0080X0 13B0147 Sealing ring GB9877.2-88; W170×200×15
01E0080X0 12B0365 O-ring GB3452.1-92; 355×5.3; YI9424
01E0080X0 09B0002 Rivet; GB827-86; 2×5; 1035
01E0080X0 07B0066 retaining ring GB893.1-86; 150
01E0080X0 07B0055 Retaining ring
01E0080X0 07B0049 retaining ring GB894.1-86; 45
01E0080X0 06B0177 Washer; 45
01E0080X0 06B0055 Washer; 27; AGGL
01E0080X0 06B0019 Washer; GB93-87; 20; 65Mn
01E0080X0 06B0014 Washer; GB93-87; 18; 65Mn
01E0080X0 06B0006 Washer; GB93-87; 8; 65Mn
01E0080X0 06B0002 Washer; GB93-87; 10; 65Mn
01E0080X0 04B0049 screw; GB70-85; M8×25-8.8-Zn.D; STL
01E0080X0 03B0406 Vent plug Z1/8 inch-27
01E0080X0 03B0212 Screw plug
01E0080X0 03B0150 Nut; GB6171-86; M20×1.5-8-Zn.D; STL
01E0080X0 01B0362 Rim bolt 20×1.5×111; 40Cr
01E0080X0 01B0043 Bolt
01E0080X0 00D0425 Rear swing bracket
01E0080X0 00D0424 Front swing bracket
01E0080X0 00B0246 bolt; GB5783-86; M16×55-10.9-Zn.D; STL
01E0080X0 00B0095 bolt; GB5783-86; M16×45-10.9-Zn.D; STL
01E0080X0 00B0057 bolt; GB5783-86; M14×45-8.8-Zn.D; STL
01E0080X0 00B0019 Bolt; GB5783-86; M10×30-8.8-Zn.D; STL
01E0080X1 01B0167 Bolt; GB5785-86; M24×2×130-10.9-Zn.D; STL
01E0080X1 00A0260 pin; 35
03E0038 06B0176 Washer; 45
03E0038 06B0177 Washer; 45
03E0038 04B0008 Reaming screw
03E0038 51C0076 Front and rear axle drive shaft assembly; assembly parts
51C0072 51C0073 Front drive shaft assembly; assembly parts
51C0072 06B0013 Washer; GB93-87; 14; 65Mn
51C0072 04B0008 Reaming screw
51C0072 04B0007 Reaming bolt; 45
51C0072 03B0025 Lock nut; M12; assembly
03E0038 41C0089 Front drive shaft and support assembly; assembly parts
03E0038 04B0007 Reaming bolt; 45
03E0038 03B0025 Lock nut; M12; assembly
03E0038 00B0246 Bolt; GB5783-86; M16×55-10.9-Zn.D; STL
12C2407X1 00A0034 connector; 35
12C2407X1 00A4757 connector; cold drawn hexagonal steel 16/35
12C2407X1 01A0432 connector; 35
04E0077X1 12A0004 pad; Q235
04E0077X1 17B0019 Lower shock absorber; rubber WJ-90
04E0077X1 17B0017 Upper shock absorber; rubber WJ-90
52C0041 72A0010 Pressure plate
52C0041 63C0001 Fuel filler pipe cover assembly; assembly parts
63C0001 84A0001 Rubber stopper; rubber I-1
63C0001 77A0001X0 iron chain
63C0001 53A0007 pipe cover; Q235
63C0001 52A0001 pressure plate; Q235
63C0001 16D0001 Tie rod; WELD
52C0041 12B0287 O-ring; GB3452.1-92; 36.5×3.55; YI9424
