402222 LG853.02.01-003 guid gear seat for LONKING wheel loader PARTS
| 1 | 403504 | 圆柱销 | Pillar pin | 6 | LG853.03.01.05-003 |
| 2 | GB/T276 | 球轴承 122 | Ball bearing 122 | 1 | |
| 3 | 403501 | 直接挡受压盘 | Direct speed press disc | 1 | LG853.03.01.05-001 |
| 4 | GB/T6170 | 螺母 M8 | Nut M8 | 12 | |
| 5 | GB/T93 | 垫圈 8 | Washer 8 | 12 | |
| 6 | 403505-506 | 直接挡主动片 | Direct speed driving disc | 2 | LG853.03.01.05.01 |
| 7 | 403502 | 直接挡轴 | Direct speed shaft | 1 | LG853.03.01.05-002 |
| 8 | 403507 | 直接挡从动片 | Direct speed driven disc | 1 | LG853.03.01.05-004 |
| 9 | GB/T5782 | 螺栓 M8×20 | Bolt M8×20 | 12 | |
| 10 | GB/T83-94 | 圆柱滚子轴承NJ204E （20X47X14） | Roller bearing NJ204E（20X47X14） | 1 | |
| 11 | GB/T894.1 | 挡圈 65 | Spacer 65 | 1 | |
| 12 | 403513 | 碟形弹簧 | Disc spring | 1 | LG853.03.01.05-007 |
| 13 | 403508A-510A | 直接挡活塞总成 | Direct speed piston assembly | 1 | LG853.03.01.05.02 |
| 14 | 403517 | 调整圈 | Spacer | 1 | LG853.03.01.05-008 |
| 15 | 403010A | 外密封环 | External sealing ring | 1 | |
| 16 | 403101 | 旋转油封 | Rotary seal | 1 | LG853.03.01.01-001 |
| 17 | 403512A | 直接挡油缸体 | Direct speed cylinder body | 1 | LG853.03.01.05-006 |
| 18 | 403511J | 中间轴输出齿轮 | Intermediate shaft output gear | 1 | LG50EX.03.01.02-001 |
| 19 | GB/T5785 | 螺栓 M12×1.25×100 | Bolt M12×1.25×100 | 1 | |
| 20 | 403518B | 双孔止动垫圈 | Stop washer | 12 | LG853.03.01.05-009 |
| 21 | 403516 | 销 Ф10×30 | Pin Ф10×30 | 12 | LG853.03.01.05-010 |
| 22 | GB/T276 | 球轴承 411 | Ball bearing 411 | 3 | |
| 23 | 403102 | 旋转油封 | Rotary seal | 1 | LG853.03.01.01-002 |
