Description

4021000173 BEARING (1)

1 4110001933001 支座BL50-1B-1 Brake anchorage Y 1
2 4013000163 P-螺母GB6170-M6EpZn Nut Y 4
3 4110001933002 弹簧BL50-1-5 Spring Y 2
4 4110001933003 支架BL50-1-2 Bracket Y 1
5 4110001933004 锁片BL50-1-11 Lock plate Y 1
6 4013000016 螺母GB6170-M16EpZn-8 Nut Y 2
7 4110001933005 固定轴BL50-1B-8 Centering mandrel Y 2
8 4110001933006 制动支架BL50-1B-10 Bracket Y 1
9 4110001933007 拉柄BL50-1-3 Pull rod Y 1
10 4110001933008 拉线支架BL50-1-9 Attaching bracket Y 1
11 4011000082 螺栓GB5783-M10*25EpZn-8.8 Bolt Y 2
12 4110001933009 限位螺栓BL50-1-4 Screw Y 1
13 4011000723 螺栓GB5783-M8*20-8.8 Bolt Y 1
14 4110001933010 O形圈1.9×19 O-ring Y 2
15 4011000421 螺栓GB5783-M16*65EpZn-8.8 Screw Y 2
16 4110001933011 摩擦片BL50-1-7 Friction disc Y 1
17 4110001933012 摩擦片BL50-1-6 Friction disc Y 1
18 4110001933013 挡块BL50-1B-12 Block Y 1
19 4110001933014 垫片Φ14.5RDFZ-1 Shim Y 1
20 4110001933015 扭转弹簧BL50-1-15 Spring Y 1
21 4110001933016 多头螺纹组合BL50-1B-13 Bolt on edge kit Y 1

1 29050015111 阀块 Valve housing N 1
2 29050015251 盖板 Cover N 1
3 29050015132 密封垫 Gasket N 1
4 4015000213 垫圈GB93-6EpZn-65Mn Washer Y 16
5 29050015141 弹簧 Spring Y 5
6 29050015151 阀杆 Valve slide N 5
7 29050015161 阀杆 Valve slide N 1
8 29050015171 螺塞 Plug N 1
9 29120014931 垫圈 Washer Y 1
10 4030000367 测试接头SMK20-M14×1.5-PC Joint Y 1
11 29050015181 固定座 Valve plate N 1
12 29050015192 密封垫 Gasket N 1
13 4014000278 螺钉GB70.1-M6*25EpZn-8.8 Screw Y 16
14 29050025362 电磁阀线束总成 Solenoid N 5
15 29050015211 弹簧 Spring Y 1
16 29050015231 弹簧导向套 Spring guide N 1

1 4011000289 螺栓GB5783-M6*16EpZn-8.8 Bolt Y 6
2 4015000207 垫圈GB97.1-6EpZn-300HV Washer Y 6
3 29050015401 端盖 Cover N 2
4 4030000211 O形圈GB3452.1-30.0*2.65G O-ring Y 4
5 29050015391 间隔套 Spacer sleeve N 2
6 29050015371 弹簧 Spring Y 2
7 29050015361 弹簧 Spring Y 2
8 29050015351 阀体 Valve housing N 1
9 29050015411 调整塞 Trimmer plug N 2
10 29050015421 阀杆 Valve slide N 2
11 29050015381 弹簧 Spring Y 2
12 29050015431 弹簧导向套 Spring guide N 2
13 4015000295 挡圈GB894.1-14-65Mn Retaining ring Y 2

1 4120002109 测压接头SMK20-M14*1.5-VE-SK Joint Y 1
2 4041000767 O形圈LGB168-11124 O-ring Y 1
3 4014000058 螺钉GB70.1-M6*20EpZn-8.8 Screw Y 4
4 4015000207 垫圈GB97.1-6EpZn-300HV Washer Y 4
5 29050015011 端盖 Cover N 1
6 29050015451 垫片 Shim Y 1
7 29050015061 阀杆 Valve slide N 1
8 29050015081 阀体 Valve housing N 1
9 29050015071 垫圈 Washer N 1
10 29050015041 弹簧 Spring Y 1
11 29050015001 端盖 Cover N 1
12 29050015441 垫片 Shim Y 1
13 29050015031 弹簧 Spring Y 1
14 29050015051 阀杆 Valve slide N 1
15 29050015021 弹簧 Spring Y 1
16 29050015331 垫圈 Washer N 1
17 29050015341 螺塞 Plug N 1
