Description

4021000044 ROLLING BEARING GB297-32220 wheel loader spare parts LG936L LG933L

1 4011000084 螺栓 GB5783-M10*30EpZn-8.8 BOLT 10
2 4015000025 垫圈 GB93-10-65Mn WASHER 10
3 2907000767 盖 COVER 1
4 2907000916 定位块 LOCK BLOCK 1
5 2907000768 O 型密封圈 O－RING 1
6 4120000080 螺塞 Q/ZB286-ZG3/4″-Q235A PLUG 1
7 4090000007 钢球 GB308-8-GCr15 STEEL BALL 3
8 4090000006 钢球 GB308-17.462-GCr15 STEEL BALL 1
9 3050900044 轮辋螺栓 RIM BOLT 10
10 2907000766 行星轮架 CARRIER OF PLANT GEAR 1
11 3050900043 行星齿轮轴 PLANT GEAR SPINDLE 3
12 3050900052 垫片 SPACER 6
13 3050900042 挡环 RING SNAP 6
14 3050900041 行星齿轮 PLANET GEAR 3
15 4090000003 滚针 GB309-4*38-GCr15 ROLLER 84
16 4015000046 挡圈 GB894.1-50-65Mn RING SNAP GB894.1-50-65Mn 1
17 3050900040 太阳轮 GEAR－SUN 1
18 3050900050 半轴 DIFFERENTIAL AXLE 1
19 4014000118 螺钉 GB70-M8*1*20-8.8 SCREW GB70-M8*1*20-8.8 1
20 4015000036 垫圈 GB93-8-65Mn WASHER 1
21 3050900047 圆螺母 ROUND NUT 1
22 3050900037 内齿轮 AXLE RING GEAR 1
23 3050900045 O 形圈 O－RING 1
24 4021000044 滚动轴承 GB297- 32220 ROLLING BEARING GB297- 32220 1
25 3050900046 轮毂 HUB WHEEL 1
26 4015000029 垫圈 GB93-18-65Mn WASHER GB93-18-65Mn 10
27 4013000136 螺母 GB6171-M18*1.5EpZn-8 NUT GB6171-M18*1.5EpZn-8 10
28 4021000045 滚动轴承 GB297-32021 ROLLING BEARING GB297-32021 1
29 3050900051 轴承隔套 BEARING COWL 1
30 4030000046 骨架油封 HG4-692-PD130*160*12 FRAME OIL SEAL 1
31 3050900048 垫片 BACKUP PLATE 1
32 3050900049 油封端盖 OIL SEAL COVER 1
33 4015000036 垫圈 GB93-8-65Mn WASHER GB93-8-65Mn 6
34 4011000195 螺栓 GB5783-M8*35EpZn-8.8 BOLT GB5783-M8*35EpZn-8.8 6

1 4120000414 多路阀 DF-25B2-16 CONTROL VALVE DF-25B2-16 1
2 4011000056 螺栓 GB5782-M12*145EpZn-8.8 BOLT GB5782-M12*145EpZn-8.8 1
3 4015000168 垫圈 GB97.1-12EpZn-300HV WASHER GB97.1-12EpZn-300HV 12
4 4011000058 螺栓 GB5782-M12*175EpZn-8.8 BOLT GB5782-M12*175EpZn-8.8 1
5 2912000502 多路阀回油钢管 OIL RETURN TUBE OF THE CONTROL VEVLE 1 部件
6 4030000031 O 形圈 GB3452.1-42.5*3.55G O-RING GB3452.1-42.5*3.55G 1
7 4011000475 螺栓 GB16674-M10*30EpZn-8.8 BOLT GB16674-M10*30EpZn-8.8 60
8 4041000705 软管 LGB163012112 TUBE LGB163012112 1
9 4041000056 分体法兰 LGB117312550 FLANGE LGB117312550 7
10 4030000029 O 形圈 GB3452.1-37.5*3.55G O-RING GB3452.1-37.5*3.55G 7
11 2912000504 管夹 CLAMP 1 部件
12 2912001097 操纵软轴 CONTROL AXIS 2
13 4011000137 螺栓 GB16674-M12*20EpZn-8.8 BOLT GB16674-M12*20EpZn-8.8 2
14 2912000402 固定板 CLAMPING PLATE 1 Q235A
15 2912000403 回油钢管 OIL OUT TUBE 1 部件
16 2912000404 二通块 TWO-WAY MASS 1 部件
17 4011000458 螺栓 GB16674-M8*20EpZn-8.8 BOLT GB16674-M8*20EpZn-8.8 14
18 4011000477 螺栓 GB16674-M12*35EpZn-8.8 BOLT GB16674-M12*35EpZn-8.8 8
19 4120001071 操纵机构 LG12-936CZJG01 CONTROL SYSTEM LG12-936CZJG01 1
20 4041000532 软管 LGB162012105 TUBE LGB162012105 1
21 4011000556 U 形螺栓 JB/ZQ4321-33Zn-Q235A·F U-BOLT JB/ZQ4321-33Zn-Q235A·F 7
22 4013000007 螺母 GB6170-M10EpZn-8 NUT GB6170-M10EpZn-8 19
23 4015000162 垫圈 GB97.1-10EpZn-300HV WASHER GB97.1-10EpZn-300HV 19
24 4041000043 分体法兰 LGB117310490 FLANGE LGB117310490 10
25 4041000698 软管 LGB107010125 TUBE LGB107010125 1
26 4030000026 O 形圈 GB3452.1-32.5*3.55G O-RING GB3452.1-32.5*3.55G 11
27 2912000510 固定支架 FRAME 1 Q235A
28 4011000447 螺栓 GB16674-M10*20EpZn-8.8 BOLT GB16674-M10*20EpZn-8.8 2
29 2912000405 多路阀进油钢管 INPUT TUBE OF THE CONTROL VALVE 1 部件
30 4041000774 螺塞 LGB135-01422 PLUG LGB135-01422 2
31 4041000767 O 形圈 LGB168-11124 O-RING LGB168-11124 3
32 4011000263 螺栓 GB5782-M12*130EpZn-8.8 BOLT GB5782-M12*130EpZn-8.8 2
33 4011000230 螺栓 GB16674-M10*65EpZn-8.8 BOLT GB16674-M10*65EpZn-8.8 1
34 2912000503 多路阀固定板 CLAMPING PLATE OF CONTROL VALVE 1 Q235A
35 4013000011 螺母 GB6170-M12EpZn-8 NUT GB6170-M12EpZn-8 8
36 2912000008 铰接头 TIE-IN 2 Q235A
37 4120001072 操纵机构 LG12-936CZJG02 CONTROL SYSTEM LG12-936CZJG02 1 选用
38 4011000447 螺栓 GB16674-M10*20EpZn-8.8 BOLT GB16674-M10*20EpZn-8.8 2
39 2914000002 固定板 CLAMPING PLATE 1 Q235A
40 4120000868 转斗油缸 HSGF-140*80*502－952 TILT CYLINDER HSGF-140*80*502－952 1
41 2914000402 转斗指示杆 INDICATING ROD OF BUCKET 1 部件
42 2914000004 转斗指示板 CONDUIT OF INDICATING ROD 1 Q235A

43 4041000703 软管 LGB106010120 TUBE LGB106010120 2
44 2913000011 管夹 CLAMP 1 Q235A
45 2914000403 转斗缸大腔钢管 BIG CHAMBER TUBE OF TILT CYLINDER 1 部件
46 4011000309 螺栓 GB16674-M10*50EpZn-8.8 BOLT GB16674-M10*50EpZn-8.8 2
47 4011000473 螺栓 GB16674-M10*55EpZn-8.8 BOLT GB16674-M10*55EpZn-8.8 2
48 2914000404 转斗联钢管 A OIL TUBE ASSEMBLY OF TILT CYLINDER A 1 部件
49 2914000405 转斗联钢管 B OIL TUBE ASSEMBLY OF TILT CYLINDER B 1 部件
50 4041000774 螺塞 LGB135-01422 PLUG LGB135-01422 1
51 2914000406 固定支架 A FRAME A 1 部件
52 2914000407 固定支架 B FRAME B 1 部件
53 4120000867 动臂油缸 HSGF-125*70*771-1240 LIFT CYLINDER HSGF-125*70*771-1240 2
54 4030000279 O 形圈 GB3452.1-25*3.55G O-RING GB3452.1-25*3.55G 8
55 4011000309 螺栓 GB16674-M10*50EpZn-8.8 BOLT GB16674-M10*50EpZn-8.8 8
56 4011000164 螺栓 GB16674-M10*35EpZn-8.8 BOLT GB16674-M10*35EpZn-8.8 8
57 2913000402 左动臂缸小腔钢管 OIL TUBE OF SMALL CHAMBER LEFT LIFTING CYLINDER 1 部件
58 2913000861 动臂联三通钢管 THREE OF TUBE OF LIFT CYLINDER 2 部件
59 2913000867 阀至右动臂缸大腔钢管 TUBE OF VALVE TO BIG CHAMBER OF RIGHT RIGHT CYLINDER 1 部件
60 4041000137 分体法兰 LGB117306400 FLANGE LGB117306400 4
61 2913000869 阀至左动臂缸大腔钢管 TUBE OF VALVE TO BIG CHAMBER OF RIGHT LIFT CYLINDER 1 部件
62 2913000871 阀至左动臂缸小腔钢管 TUBE OF VALVE TO SMALL CHAMBER OF RIGHT LIFT CYLINDER 1 部件
63 2913000407 左动臂缸大腔钢管 OIL TUBE OF BIG CHAMBER LEFT LIFTING CYLINDER 1 部件
64 2913000408 管夹 CLAMP 2 Q235A
65 4011000488 螺栓 GB16674-M10*16EpZn-8.8 BOLT GB16674-M10*16EpZn-8.8 6
66 4011000490 U 形螺栓 JB/ZQ4321-25Zn-Q235A·F U-BOLT JB/ZQ4321-25Zn-Q235A·F 4
67 2913000409 固定支架 A FRAME A 1 部件
68 2913000895 动臂缸胶管 OIL PIPE OF LIFTING CYLINDER 4 部件
69 2913000411 固定支架 B FRAME B 1 部件
70 2913000412 右动臂缸大腔钢管 OIL TUBE OF BIG CHAMBER RIGHT LIFTING CYLINDER 1 部件
71 2913000413 右动臂缸小腔钢管 OIL TUBE OF SMALL CHAMBER RIGHT LIFTING CYLINDER 1 部件
72 2913000873 阀至右动臂缸小腔钢管 TUBE OF VALVE TO SMALL CHAMBER OF RIGHT RIGHT CYLINDER 1 部件
73 4017000013 喉箍 JB8870-d90 ADMAS APPLE JB8870-d90 4 部件
74 2911000402 工作泵吸油钢管 INTAKE OIL TUBE OF PUMP 1 部件
75 4011000337 螺栓 GB16674-M12*60EpZn-8.8 BOLT GB16674-M12*60EpZn-8.8 4
76 4030000235 0 形圈 GB3452.1-43.7*3.55G O-RING GB3452.1-43.7*3.55G 1
77 2911000403 工作泵吸油胶管 INTAKE OIL HOSE OF PUMP 1 部件
78 2911000404 工作泵出油胶管 OUT OIL TUBE OF PUMP 1
79 4013000011 螺母 GB6170-M12EpZn-8 NUT GB6170-M12EpZn-8 4
80 4012000003 螺柱 GB898-M12*35EpZn-8.8 SNAIL POLE GB898-M12*35EpZn-8.8 4
81 4120000401 工作泵 CBGj3100A WORKING PUMP CBGJ3100A 1 部件
82 2911000004 泵用密封垫 SEALING WASHER
