Description

2894940X Nitrogen Oxide Sensor

3917530
Pump, Fuel Injection
1
OPTION FP97136
CPLTO858 “VP-14” type (EPA/CARB Certi-
fied) fuel pump for 105 ВНР turbocharged
“B” series 4 cylinder engine at 2500 RPM
with a peak torque of 265 lbs ft at 1700 RPM.
Has 24 volt atr fuel solenoid and 2.0mm
tubing. This pump is also equipped with KSB.
With FR9273 and FE9701.
1
3917531
Pump, Fuel Injection

S-965-E
Plug, Pipe
1
1/16 NPT
2
3018888
Connector, Female
2
3
3901446
Screw, Hex Flange Head Cap
1
M8x 1.25×60
4
3901836
Seal, О Ring
1
5
3903380
Seal, Banjo Connector
1
6
3903728
Washer, Sealing
4
7
3903729
Screw, Banjo Connector
M12 x 1.00×20
8
3905307
Screw, Banjo Connector
1
M6x 1.00×14
9
3906391
Screw, Socket Head Cap
M6x 1.00×16
10
3914897
Support, Timing Advance
1
11
3914898
Tube, Fuel Supply
1
12
3914902
Adapter, Timing Advance
1
13
3914903
Tube, Fuel Transfer
1
14
3914908
Plate, Cover
1
15
3915451
Hose, Flexible
1
16
3917532
Pump, Fuel Injection
1
OPTION FP97138
CPL#0858 “VP-14” type (EPA/CARB Certi-
fied) fuel pump for 105 ВНР turbocharged
“B” series 4 cylinder engine 2500 RPM with
a peak torque of 265 lbs. ft. at 1700 RPM.
Has 24 volt atr fuel solenoid and 2.0mm
tubing. For use when a remote mounted KSB
is required. With FR9273 and FE9701.
1
S-965-E
Plug, Pipe
1
1/16 NPT
2
3018888
Connector, Female
2
3
3901446
Screw, Hex Flange Head Cap
1
M8x 1.25×60
4
3901836
Seal, О Ring
1
5
3903380
Seal, Banjo Connector
1
6
3903728
Washer, Sealing
4
7
3903729
Screw, Banjo Connector
M12 x 1.00 x 20
8
3905307
Screw, Banjo Connector
1
M6 x 1.00 x 14
9
3906391
Screw, Socket Head Cap
M6x 1.00×16
10
3914897
Support, Timing Advance
1
11
3914898
Tube, Fuel Supply
1
12
3914902
Adapter, Timing Advance
1
13
3914903
Tube, Fuel Transfer
1
14
3914908
Plate, Cover
1
15
3915451
Hose, Flexible
1
16
3917533
Pump, Fuel Injection
1
