Description

28220003591 Lower hinge pin SDLG spare parts

11.2 7200001693 COVER PLATE 4644306363
11.3 7200001694 SEAL 4644306364
11.4 7200001695 OIL CHANNEL PLATE 4644306365
11.5 4110000042119 CAP SCREW 0636 102 173
11.6 7200001697 WASHER (8.4)0630003006
11.7 7200001698 SEAL 4644306497
11.8 7200001699 COVER PLATE 4644306508
11.9 4110000042110 GASKET 4644 306 370
11.10 4110000042123 CAP SCREW 0736 101 205
11.11 4110000042121 CAP SCREW 0736 101 203
11.12 4110000042122 CAP SCREW 0736 101 204
11.13 7200001750 PLUG (M10*1)0636302053
11.14 7200001705 O-RING (8*1.5)0634303280
12.1 7200001707 VALVE BODY 4644306558
12.2 4110000042117 SCREW-IN SLEEVE 4644 306 566
12.3 7200001709 O-RING (15*2)0634306524
12.4 7200001710 PRESSURE SPRING 0732042314
12.5 7200001711 VALVE ROD 4644306597
12.6 7200001712 AJUSTING SHIM (10*16*1)0630004037
12.7 7200001713 PERMEABILITY PLUG 4644306401 A=0.6
12.8 4110000042100 ORIFICE A=0.7 4644 306 402
12.9 4110000042102 ORIFICE A=0.8 4644 306 403
12.10 4110000042099 ORIFICE A=0.65 4644 306 521
12.11 4110000042101 ORIFICE A=0.75 4644 306 522
12.12 4110000042103 ORIFICE A=0.85 4644 306 404
12.13 4110000042104 ORIFICE A=0.90 4644 306 531
12.14 4110000042105 ORIFICE A=0.95 4644 306 554
12.15 7200001705 O-RING (8*1.5)0634303280
12.16 7200001715 O-RING (6*1.5)0634306170
12.17 7200001716 VALVE ROD 4644306376
12.18 7200001717 PRESSURE SPRING 0732042315
12.19 7200001718 PRESSURE SPRING 0732042316
12.20 7200001719 VALVE ROD 4644306377
12.21 7200001720 VALVE ROD 4644306509
12.22 7200001721 PRESSURE SPRING 0732042317
12.23 7200001722 BALE 4644306379
12.24 7200001723 PRESSURE SPRING 0770060648
12.25 7200001725 VALVE ROD 4644306381
12.26 7200001726 VALVE ROD 4644306380
12.27 7200001727 SEAL PLATE 4644306584
12.28 7200001731 VALVE ROD 4644306383
12.29 7200001733 VALVE ROD 4644306384
12.30 4110000042098 REDUCTION VALVE 4644 306 578
12.31 7200001735 RING 0730007565
12.32 7200001736 BALE 4644306580
12.33 7200001737 PRESSURE SPRING 0732042024
12.34 7200001743 SCREW (M5*12)0636101129
12.35 7200001739 STEEL BALL 0635460005
12.37 7200001741 BALE 1043326045
12.38 7200001742 WASHER 0730064292
12.39 7200001744 CABLE POLE 4644206035
12.40 7200001745 SCREW (M6*14)0636101478
12.41 7200001746 BALE 4644306399
12.42 7200001747 COVER PLATE 4644206039
12.43 4110000042006 O-RING 0634 349 606
12.44 7200001749 CLAMP 4644306388
12.45 7200001750 PLUG (M10*1)0636302053
12.46 7200001752 STEEL BALL 0635460027
12.47 4110000042118 COMPR.SPRING 0732 041 226
12.48 7200001664 PLUG (M8*1.5)0636302014
12.49 7200001757 JOINT NUT (L16BM)0637842525
12.50 7200001759 VALVE COVER 0644306511
12.51 7200001760 SCREW (M6*20)0636101012
12.52 7200001761 WASHER (6.4)0630003004
12.53 7200001763 VALVE ROD 4644306390 A=20.5
12.54 4110000042096 PISTON A=21.5 4644 306 440
12.55 4110000042095 PISTON A=21 4644 306 517
12.56 7200001724 STAFF 0635470104
12.57 7200001728 RING 0730006344 A=2
12.58 4110000042091 RING A=3 0730 006 345
12.59 4110000042092 RING A=4 0730 006 346
12.60 4110000042093 RING A=6 0730 006 347
12.61 4110000042094 RING A=8 0730 006 348
12.62 7200001729 VALVE CORE 4644306397
12.63 7200001730 PRESSURE SPRING 0732042318
12.64 7200001732 JOINT NUT 4616306109
12.65 7200001756 O-RING 0634303144
12.66 7200001758 VALVE CORE 4644306398
12.67 4110000042042 SHIM RING 0630 004 252
12.68 7200001764 PRESSURE SPRING 0732041764
12.69 7200001767 PLUG (M20*1.5)0636302005
12.70 7200001768 O-RING 0634306198
12.71 7200001769 TUBE 0750147228
15.1 7200001663 SEAL COVER 4642301106
16.2 7200001771 SEALING RING （A18*24）0634801155
16.3 7200001664 PLUG (M8*1.5)0636302014
16.4 7200001709 O-RING (15*2)0634306524
16.5 7200001774 AJUSTING SHIM 0769140251
16.6 7200002251 AJUSTING SHIM 0630004030 18*25 1.5
16.7 4110000042047 SHIM RING 18*25 1.4 0630 004 040
16.8 4110000042048 SHIM RING 18*25 1.2 0630 004 041
16.9 4110000042046 SHIM RING 18*25 1 0630 004 042
16.10 4110000042051 SHIM RING 18*25 2.0 0630 004 242
16.11 4110000042045 SHIM RING 18*25 0.5 0630 004 262
16.12 4110000042044 SHIM RING 18*25 0.3 0630 004 263
16.13 4110000042043 SHIM RING 18*25 0.2 0630 004 264
16.14 4110000042049 SHIM RING 18*25 1.6 0630 004 287
16.15 4110000042050 SHIM RING 18*25 1.8 0630 004 288
17.1 7200001654 LEVEL TUBE 4644231179
17.2 7200002241 WASHER 4642331216
17.3 7200002232 SCREW 0636010089
17.4 7200001657 FEELER LEVER 4644231086
17.5 7200001658 PLATE 4642331056
17.6 7200001659 COVER PLATE 4644301016
17.7 7200001660 SCREW 0636015289
17.8 7200001661 PLUG 0636305016
17.9 7200001662 PACKING RING 0634801074
18.1 7200002230 SYPHON TUBE 4644221196
18.2 7200002231 WASHER 4644321244
18.3 7200002232 SCREW 0636010089
18.4 7200002233 JOINT SCREW 0737835153
18.5 7200002234 O-RING (18*2.5)0634306202
18.6 7200001864 O-RING 0634306523
18.7 7200002236 TUBE 0750147257
18.8 7200002237 TUBE 0750147208
18.9 4110000042114 RAPID CONNECTOR 0659 160 025
18.10 7200002238 TUBE 0750147036
18.11 7200002239 TUBE 0750147117
18.12 7200002240 JOINT PLUG (L12AM)0637842509
18.13 7200002241 WASHER 4642331216
18.14 7200002242 SCREW (M8*30)0636101031
19.3 4110000042010 PLUG 6029 199 005
19.5 7200001779 JOINT NUT 0737843077
19.8 7200001929 NUT 0637011539
19.9 4110000042115 LOCKING NUT M14*1.5 0637 011 540
20.1 4110000042107 CONN. HOUSING 4644 330 385
20.2 7200001454 SCREW (M10*50)0636010460
20.3 4110000042124 SPANNSTIFT 0631 329 100
20.4 7200001456 PIN 0631329072
20.5 7200001457 COVER 4139301485
20.6 7200001458 DIAPHRAGN 4644330239
20.7 4110000042109 HEXAGON SCREW 9636 016 221
20.8 7200001460 WASHER 4644330228
20.9 7200001461 WASHER (13)0630001049
20.10 7200001462 WASHER 4166330123
20.11 7200001463 O-RING (25×3)0634313260
20.12 7200001464 CLASP (30×1.2)0630502015
20.13 7200001465 COVER 4644330242
20.14 7200001466 SCREW (M10x12)0636015169
20.15 4110000042125 INTERM. RING 4644 330 222
20.16 7200001468 SCREW (M12x30)0636900127
22.1 7200001470 DRIVEN SHAFT 4644302188
22.2 7200001471 SPANNSTIFT (2.5×5)0631329267
22.3 7200001472 SPANNSTIFT (1.5×5)0631329124
22.4 7200001473 BALL BEARING 0750116139
22.5 7200001474 WASHER 4607302033 S=0.3
22.6 4110000042066 SHIM S=0.5 4607 302 034
22.7 4110000042067 SHIM S=0.6 4607 302 014
22.8 4110000042068 SHIM S=0.7 4607 302 013
22.9 4110000042069 SHIM S=0.8 4607 302 012
22.10 4110000042070 SHIM S=0.9 4607 302 011
