Description

13B0220 oil seal 150x180x15 for LIUGONG PART

02D1036 Gearbox left support; welding parts
03B0210 Lock nut; M16; assembly
22C1370X2 right bearing; dedicated for diesel transformers; ASSY
06B0019 Washer; GB93-87; 20; 65Mn
01B0321 Bolt; GB5783-86; M20×55-10.9-Zn.D; STL
02D1035 Gearbox right support; welding parts
05B0083 Stud; GB898-88; AM16×40-10.9-Zn.D; STL
42C0249XD gearbox
42C0249 gearbox; ASSY
00C2776X2 Oil filter pipeline assembly; dedicated for diesel transformers; ASSY
30C0878 connector; ASSY
31C0501 Right-angle connector; M45×2; ASSY
30C0095 connector; assembly parts
00C0900X2 Fan motor pipe assembly; ASSEM
11C1757 Gear pump; PT197A486**ZA12-14; ASSY
06B0008 Washer; GB93-87; 12; 65Mn
00B0017 Bolt; GB5783-86; M12×30-8.8-Zn.D; STL
80A0196 sealing gasket; oil-resistant rubber sheet NY150
00C0887X2 Pump suction line assembly; ASSEM
06B0015 Washer; GB93-87; 16; 65Mn
10D1659 steel pipe assembly; welded parts
04B0124 Screw; GB70-85; M16×45-8.8-Zn.D; STL
12B0451 ​​O-ring AS568A-241; φ98.02×3.53
11C0619 vane pump; ASSEM
12B0557 O-ring; 16.36×2.21; Y19424
11C0329 vane pump; ASSY
00A2577 connector; 35
12B0333 O-ring; GB3452.1-92; 31.5×2.65; YI9424
12B0332 O-ring; GB3452.1-92; 38.7×2.65; YI9424
84A0098 air-conditioning triangle belt; cloth rubber
00D1215 Diesel engine support; welding parts
46C6409 Compressor bracket assembly; ASSY
00B0085 Bolt; GB5783-86; M8×25-8.8-Zn.D; STL
46C0754 Tensioner and tensioner assembly; assembly parts
00B0022 Bolt; GB5783-86; M6×16-8.8-Zn.D; STL
71A1240 Air-conditioning compressor bracket; ZG270-500
06B0003 Washer; GB93-87; 6; 65Mn
00B0199 Bolt; GB5782-86; M8×80-8.8-Zn.D; STL
22A6981 Bent plate; Q235
06B0005 Washer; GB97.1-85; 8-140HV-Zn.D; STL
00B0002 Bolt; GB5783-86; M10×35-8.8-Zn.D; STL
06B0006 Washer; GB93-87; 8; 65Mn
06B0001 Washer; GB97.1-85; 10-140HV-Zn.D; STL
00B0019 Bolt; GB5783-86; M10×30-8.8-Zn.D; STL
06B0002 Washer; GB93-87; 10; 65Mn
06B0024 Washer; GB97.1-85; 6-140HV-Zn.D; STL
19A6276 Bent plate; Q235
46C0752 compressor; assembly parts
46C8131 warm air inlet valve; ASSY
46C0487 warm air inlet valve; fittings
46C4135X2 rear frame circuit; ASSY
30B0226 water temperature sensor; fittings
00A0522 Oil pressure sensor transition joint; cold drawn hexagonal steel 35
30B0225 Torque converter oil temperature sensor; assembly parts
40C0454X1 intake and exhaust system components; assembly parts
00B0059 Bolt; GB5783-86; M16×35-8.8-Zn.D; STL
23A2617 Bent plate; Q235
06B0059 Washer; GB96-85; 12-140HV-Zn.D; STL
06B0015 Washer; GB93-87; 16; 65Mn
06B0012 Washer; GB97.1-85; 16-140HV-Zn.D; STL
03B0003 Nut; GB6170-86; M12-8-Zn.D; STL
23A3104 curved plate; Q235
06B0030 Washer; GB96-85; 10-140HV-Zn.D; STL
06B0008 Washer; GB93-87; 12; 65Mn
06B0007 Washer; GB97.1-85; 12-140HV-Zn.D; STL
06B0002 Washer; GB93-87; 10; 65Mn
03B0053 Nut; GB6170-86; M10-8-Zn.D; STL
00B0013 Bolt; GB5783-86; M12×40-8.8-Zn.D; STL
40C0255 diesel engine; ASSY
SP127636 generator
SP100569 starting motor
SP132205 water pump
SP116641 belt
SP113526 thermostat
SP127039 injector
SP124961 fuel pump
SP123757 turbocharger
SP125663 flameout solenoid valve
SP106455 oil pump
SP106451 upper repair kit
SP112210 lower repair kit
SP112261 air filter
00E0932 Cooling system; ASSY
06B0024 Washer; GB97.1-85; 6-140HV-Zn.D; STL
06B0003 Washer; GB93-87; 6; 65Mn
06B0002 Washer; GB93-87; 10; 65Mn
01B0321 Bolt; GB5783-86; M20×55-10.9-Zn.D; STL
00B0085 Bolt; GB5783-86; M8×25-8.8-Zn.D; STL
35C1005 clamp; ASSY
21A5440 Pallet; Q235
48D0363 connection board; WELD
38A3546 Sewer steel pipe; 0Cr18Ni9
38A3545 Intercooler steel pipe; 0Cr18Ni9
00B0029 Bolt; GB5783-86; M10×40-8.8-Zn.D; STL
38A3542 Intercooler steel pipe; 0Cr18Ni9
85A3200 sound-absorbing board; SPONGE
32A0968 drain hose; EPDM
27A0294 Button nail; Q195
22C1000 Heat insulation bracket; ASSY
03B0021 Nut; GB6170-86; M8-8-Zn.D; STL
