Description
13023179 Muffler CDM833 CDM843 LONKING
1 |
ZL30E.5G-1 |
箱体 |
Transmission case |
1 |
|
2 |
GB/T119-2000 |
圆柱销 |
Cylindrical pin |
2 |
|
3 |
ZL30E.5-2A |
箱盖 |
Transmission cover |
1 |
|
4 |
ZL30E.5-3 |
密封垫 |
Seal gasket |
1 |
|
5 |
ZL30E.5.1 |
一轴离合器总成 |
Shaft Ⅰ clutch assembly |
1 |
|
6 |
ZL30E.5.3 |
二轴离合器总成 |
Shaft Ⅱ clutch assembly |
1 |
|
7 |
ZL30E.5.4 |
三轴离合器总成 |
Shaft Ⅲ clutch assembly |
1 |
|
8 |
ZL30E.5-4 |
倒挡齿轮 |
Reverse gear |
1 |
|
9 |
GB893.1-86 |
挡圈90 |
Spacer 90 |
3 |
|
10 |
GB/T276-94 |
轴承 6308 |
Bearing 6308 |
1 |
40×90×28 |
11 |
ZL30E.5-7 |
轴套 |
Shaft sleeve |
1 |
|
12 |
GB894.1-86 |
挡圈40 |
Spacer 40 |
1 |
|
13 |
ZL30E.5-5 |
轴套 |
Shaft sleeve |
1 |
|
14 |
ZL30E.5-6 |
倒挡齿轮轴 |
Reverse gear shaft |
1 |
|
15 |
GB3452.1-82 |
O型圈45×2.65 |
O-ring 45×2.65 |
1 |
|
16 |
ZL30E.5-26A |
密封垫 |
Seal gasket |
1 |
|
17 |
GB93.1-87 |
垫圈10 |
Washer 10 |
47 |
|
18 |
GB/T5782-2000 |
螺栓M10×30 |
Bolt M10×30 |
15 |
|
19 |
ZL30E.5.2 |
一轴端盖总成 |
Shaft Ⅰ end cover assembly |
1 |
|
20 |
ZL30E.5-8 |
密封垫 |
Seal gasket |
2 |
|
21 |
GB93.1-87 |
垫圈12 |
Washer 12 |
35 |
|
22 |
GB5782-2000 |
螺栓M12×35 |
Bolt M12×35 |
29 |
|
23 |
ZL30E.5.9A |
二轴端盖总成 |
Shaft Ⅱ end cover assembly |
1 |
|
24 |
ZL30E.5.5A |
三轴端盖总成 |
Shaft Ⅲ end cover assembly |
1 |
|
25 |
ZL30E.5-10 |
密封垫 |
Seal gasket |
1 |
|
26 |
ZL1615.2A |
制动器 |
Brake |
1 |
|
27 |
ZL30E.5-16 |
前轴承盖 |
Front bearing cover |
1 |
|
28 |
ZL30E.5-13 |
调整垫圈 |
Adjusting washer |
1set |
|
29 |
GB/T276-94 |
轴承 6312 |
Bearing 6312 |
2 |
60×130×31 |
30 |
ZL30E.5-12 |
轴套 |
Shaft sleeve |
1 |
|
31 |
ZL30E.5-11 |
压板 |
Press plate |
2 |
|
32 |
ZL30E.5-31 |
垫片 |
Gasket |
1 |
|
33 |
JB980-80 |
尼龙锁紧螺母M33×1.5 |
Nylon lock nut M33×1.5 |
2 |
|
34 |
GB3452.1-82 |
O型圈42.5×5.3 |
O-ring 42.5×5.3 |
1 |
|
35 |
HG4-339-66 |
骨架油封65×90×12 |
Frame oil seal 65×90×12 |
2 |
|
36 |
ZL30E.5B.17 |
前输出法兰总成 |
Front output flange assembly |
1 |
|
37 |
ZL30E.5-15 |
密封垫 |
Seal gasket |
2 |
|
38 |
ZL30E.5-19 |
轴套 |
Shaft sleeve |
1 |
|
39 |
ZL30E.5-14A |
输出被动齿轮 |
Output driven gear |
1 |
|
40 |
GB/T5782-2000 |
螺栓M10×35 |
Bolt M10×35 |
28 |
|
41 |
GB/T 825-1988 |
吊环螺钉M16×28 |
Eye screw M16×28 |
1 |
|
42 |
ZL30E.5.20 |
透气阀总成 |
Vent assembly |
1 |
|
43 |
GB/T5782-2000 |
螺栓M12×100 |
Bolt M12×100 |
6 |
|
44 |
ZL30E.5.8 |
控制阀 |
Control valve |
1 |
|
45 |
ZL30E.5.11A |
前进挡油管 |
Forward gear oil pipe |
1 |
|
46 |
ZL30E.5-33 |
接头体 |
Adapter |
10 |
|
47 |
JB982-77 |
组合垫圈10 |
Combined washer 10 |
10 |
|
48 |
ZL30E.5.12A |
倒退挡油管 |
Reverse gear oil pipe |
1 |
|
49 |
ZL30E.5.14A |
二挡油管 |
Gear Ⅱ oil pipe |
1 |
|
50 |
ZL30E.5.15A |
一挡油管 |
Gear Ⅰ oil pipe |
1 |
|
51 |
ZL30E.5.16A |
倒挡润滑油管 |
Reverse gear lubrication oil tube |
1 |
|
52 |
GB5626.2-85 |
接头体A8 |
Adapter A8 |
2 |
|
53 |
ZL30E.5G.21 |
回油控制阀 |
Oil-return control valve |
1 |
|
54 |
ZL30E.5-18 |
接头 |
Connector |
1 |
|
55 |
GB/T5782-2000 |
螺栓M16×40 |
Bolt M16×40 |
8 |
|
56 |
GB/T93-1987 |
垫圈16 |
Washer 16 |
8 |
|
57 |
ZL30E.5.18A |
一轴润滑油管 |
Shaft Ⅰ lubrication oil pipe |
1 |
|
58 |
GB5629.2-85 |
接头体A10 |
Adapter A10 |
3 |
|
59 |
ZL30E.5.19A |
三轴润滑油管 |
Shaft Ⅲ lubrication oil pipe |
1 |
|
60 |
ZL30E.5.6 |
支架 |
Bracket |
1 |
|
61 |
ZL30E.5.13 |
加油管总成 |
Oil-filling assembly |
1 |
|
62 |
ZL30E.5-22 |
制动支座 |
Brake bracket |
1 |
|
63 |
ZL30E.5-21 |
制动立支座 |
Vertical brake bracket |
1 |
|
64 |
ZL30E.5-32 |
密封垫 |
Seal gasket |
3 |
|
65 |
ZL30E.5-29 |
调整垫圈 |
Adjusting washer |
3sets |
|
66 |
HG4-339-66 |
骨架油封55×80×12 |
Frame oil seal 55×80×12 |
1 |
|
67 |
ZL30E.5-25 |
垫圈 |
Washer |
1 |
|
68 |
ZL30E.5-30 |
密封垫 |
Seal gasket |
1 |
|
69 |
JB980-80 |
尼龙锁紧螺母M24×1.5 |
Nylon lock nut M24×1.5 |
1 |
|
