Description

12B0224 o-ring 23.6×1.8 for LIUGONG part

44C1017X1 15B0051 Double steel wire hoop; 75; ASSY
44C1017X1 32A0082 Oil suction hose; glued parts
44C1017X1 12B0289 O-ring; GB3452.1-92; 17×1.8; YI9424
44C1017X1 00A0216 pipe joint
44C1017X1 12B0339 O-ring seal; GB1235-76; 24×2.4; YI9424
44C1017X1 04A0692 Connector block
15E0844X1 21C0505 hydraulic oil tank; ASSY
21C0505 00B0059 Bolt; GB5783-86; M16×35-8.8-Zn.D; STL
21C0505 06B0087 Washer; GB96-85; 16-140HV-Zn.D; STL
21C0505 06B0015 Washer; GB93-87; 16; 65Mn
21C0505 21C0505X0 Hydraulic oil tank; ASSY
21C0505X0 00B0007 bolt; GB5783-86; M8×16-8.8-Zn.D; STL
21C0505X0 10A1502 side board; Q235
21C0505X0 06B0347 Washer; GB93-87; 10-Zn.D; 65Mn
21C0505X0 12J0002 O-ring; GB3452.1-92; 180×5.3; YI9424
21C0505X0 53C0289 Return oil filter; assembly parts
21C0505X0 12B0246 O-ring; GB3452.1-92; 200×5.3; YI9424
21C0505X0 16C0041 cover plate; ASSEM
16C0041 60A1279 shaft; 35
16C0041 53A0754 cover; 35
16C0041 36D0457 cover; WELD
21C0505X0 04A0834 flange; Q235
21C0505X0 00B0085 bolt; GB5783-86; M8×25-8.8-Zn.D; STL
21C0505X0 06B0006 Washer; GB93-87; 8; 65Mn
21C0505X0 53C0387 Air filter; ASSY
21C0505X0 04D1180 box body; WELD
21C0505X0 00B0019 Bolt; GB5783-86; M10×30-8.8-Zn.D; STL
21C0505X0 04A1052 flange; 35
21C0505X0 44C0015 Level gauge
15E0844X1 00C1853 steering pipeline; ASSY
00C1853 03B0053 Nut; GB6170-86; M10-8-Zn.D; STL
00C1853 06B0002 Washer; GB93-87; 10; 65Mn
00C1853 00B0029 Bolt; GB5783-86; M10×40-8.8-Zn.D; STL
00C1853 07C2451 Hose assembly; ASSY
00C1853 12B0821 O-ring; SAE J515:2010; 37.69×3.53; NBR-90
00C1853 12C0644 Relief valve
00C1853 15A1342 board
00C1853 06C6670 Hose assembly; ASSY
00C1853 72A0628 pressure plate; 45
00C1853 06C6671 Hose assembly; ASSY
00C1853 72A0627 pressure plate; 45
00C1853 00B0019 Bolt; GB5783-86; M10×30-8.8-Zn.D; STL
00C1853 44C0055 Flow amplification valve installation assembly; assembly parts
44C0055 03B0003 Nut; GB6170-86; M12-8-Zn.D; STL
44C0055 12B0355 O-ring; GB3452.1-92; 23.6×3.55; YI9424
44C0055 12B0292 O-ring; GB3452.1-92; 21.2×1.8; YI9424
44C0055 06B0008 Washer; GB93-87; 12; 65Mn
44C0055 06B0007 Washer; GB97.1-85; 12-140HV-Zn.D; STL
44C0055 12C0165 Flow amplification valve
44C0055 01B0217 Bolt; GB5782-86; M12×110-8.8-Zn.D; STL
44C0055 00B0017 bolt; GB5783-86; M12×30-8.8-Zn.D; STL
44C0055 31C0033 Adjustable joint; fittings
31C0033 31C0033X0 adjustable connector
31C0033 12B0285 O-ring; GB3452.1-92; 10.6×1.8; YI9424
31C0033 12B0343 O-ring seal; GB1235-76; 18×2.4; YI9424
44C0055 13A0507 connecting board; Q235
44C0055 00A0251 connector
00C1853 15D0737 pipe joint; WELD
00C1853 12B0444 O-ring; 24.99×3.53; NBR-90
00C1853 12B0289 O-ring; GB3452.1-92; 17×1.8; YI9424
00C1853 15D0736 pipe joint; WELD
00C1853 06C6701 Hose assembly; ASSY
00C1853 09C0147 Pipe clamp assembly; assembly parts
09C0147 09C0056 pipe clamp; ASSY
09C0056 21A0180 Lower pipe clamp; Q235
09C0056 21A0181 Upper pipe clamp; Q235
09C0056 83A0070 Rubber ring; Rubber I-1
09C0056 06B0008 Washer; GB93-87; 12; 65Mn
09C0056 00B0013 Bolt; GB5783-86; M12×40-8.8-Zn.D; STL
09C0147 23A3869 curved plate; Q235
09C0147 10A0294 board; Q235
09C0147 84A0101 Rubber sheet; A3-7H6Hr1
09C0147 06B0008 Washer; GB93-87; 12; 65Mn
09C0147 03B0003 Nut; GB6170-86; M12-8-Zn.D; STL
09C0147 00B0030 Bolt; GB5783-86; M8×55-8.8-Zn.D; STL
00C1853 07C2452 Hose assembly; ASSY
00C1853 72A0629 pressure plate; 45
00C1853 44C0022 Pressure measuring connector; assembly parts
00C1853 00A0302 pipe joint; 35
00C1853 12B0285 O-ring; GB3452.1-92; 10.6×1.8; YI9424
00C1853 12B0351 O-ring seal; GB1235-76; 16×2.4; YI9424
00C1853 01B0848 Bolt; GB/T5782-2000; M10×100-10.9-DK; STL
00C1853 04A1607 flange; 35
00C1853 12B0292 O-ring; GB3452.1-92; 21.2×1.8; YI9424
00C1853 07C2462 Hose assembly; ASSY
00C1853 12B0299 O-ring seal; GB1235-76; 36×3.1; YI9424
00C1853 00A0434 connector; 35
00C1853 06B0001 Washer; GB97.1-85; 10-140HV-Zn.D; STL
00C1853 01B0033 Bolt; GB5782-86; M10×80-8.8-Zn.D; STL
00C1853 12B0445 O-ring; 32.92×3.53; NBR-90
15E0844X1 00C1864 cooling pipe; ASSY
00C1864 10D6613 Steel pipe assembly; WELD
00C1864 06B0002 Washer; GB93-87; 10; 65Mn
00C1864 12B0294 O-ring; GB3452.1-92; 32.5×3.55; YI9424
00C1864 10D6612 Steel pipe assembly; WELD
00C1864 00B0018 Bolt; GB5782-86; M10×70-8.8-Zn.D; STL
00C1864 12B0292 O-ring; GB3452.1-92; 21.2×1.8; YI9424
00C1864 09C0466 Pipe clamp assembly; assembly parts
09C0466 21A3677 Upper pipe clamp; Q235
09C0466 21A3675 Lower pipe clamp; Q235
